Raymarine eS128 12.1" Combo Wi-Fi w/CHIRP/Downvison™ Navionics+ Chart & CP470 CHIRP Sounder
$3,799.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWeS128 12.1" Combo Wi-Fi w/CHIRP/Downvison™ Navionics+ NorthAmerican Coast + 18k Lake Charts & CP470 CHIRP Sounder
High Performance Multifunction Displays
Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Features:
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications:
- Screen Size: 12.1"
- Display size: 14.1" wide x 8.8" high
- Resolution: 1280 x 800 WVGA
- Built in CHIRP/DownVision™ Sonar
- Brightness: 1250 mits
- Voltage: 12V/24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x2)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes Navionics+ NorthAmerican Coast + 18k Lake Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
CP470 CHIRP Sonar Module
High-Performance Sonar Module For Offshore and Coastal Fishing
CHIRP Sonar Module
Engineered for serious anglers, the CP470 sonar module bring best-in-class target separation and high resolution CHIRP sonar imagery to Raymarine multifunction displays. Using a wide spectrum of frequencies and greater sensitivity the CP470's advanced CHIRP transceiver can see through dense schools of baitfish, identify thermoclines, and simultaneously target desired game fish.
Rated for offshore use and rough conditions, the CP470 intelligently filters out unwanted noise while producing high resolution fish targets and reliable bottom tracking.
Serious Offshore Sonar
Superior target definition and enhanced sensitivity using Raymarine's exclusive wide spectrum CHIRP sonar technology.
Target fish, identify bait, and track the sea floor down to 10,000' (3,000M) with two adjustable CHIRP sonar channels.
Stunning Detail & Clarity
With 10 times the resolution of ordinary sonars the CP470 delivers sharper, more defined fish targets and automatically filter out unwanted noise so you never miss the action below.
TruZoom magnification mode reveals extra target detail without any loss of resolution.
Easy To Customise
Choose optional low, medium, and high CHIRP frequency transducers in standard or wide-beam to match your fishing preferences.
The CP470 automatically recognizes connected transducers and adjust sonar parameters for optimized performance
View and control each CHIRP channel independently and create your own combination of full or split screen sonar windows on Raymarine's LightHouse II powered multifunction displays.
Features
-
TruZoomTruZoom provides magnified views of fish targets, bottom structure, and baitfish without loss of resolution as seen by traditional sonar
- Automatic transducer identification with Airmar Xducer ID
- Airmar Wide Beam transducer compatible
- Waterproofing Standard:IPX6 waterproof rugged aluminum enclosure
- Compatibility:aSeries | cSeries | eSeries | gS Series
- Nominal Supply Voltage:12/24 V DC
- Power Consumption:30.6W (Maximum)
- Connections:Power connection | Network connection (RayNet connector) 10/100 Mb/s | Transducer connection
Sonar Performance
- Sonar Type: Wide Spectrum CHIRP
- Power:1kW / 2kW depending on transducer
- Frequency & Channels:Dual independent CHIRP channels from 25 to 250kHz
- Depth Range:10,000' (3,000M)
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics/C-Map
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Internal/External Antenna: Internal
- Resolution (VxH): 1280 x 800
- Screen Size: 12.1'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 3,000/150
- Weather Capable: Yes
- Box Dimensions: 13"H x 10"W x 16"L WT: 20.8 lbs
Raymarine eS127 12.1" MFD Combo w/Wi-Fi, ClearPulse™ Digital Sonar & US C-Map Essentials Charts
$3,449.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWRaymarine eS127 12.1" MFD Combo w/Wi-Fi, ClearPulse Digital Sonar & US C-MAP Essentials Charts
Display
- Sleek glass bridge design with three mounting options. Bracket, surface or fully recessed flush mounting
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the multifunction rotary control and keypad
Navigation
Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
Sonar
- Internal ClearPulse Digital Sonar Available on eS77, eS97, eS127 models
- High performance CHIRP SideVision compatible with optional CP200
- Advanced CP370 1kW Digital sonar option for blue water fishing
- Offshore ready using optional CP470 and CP570 CHIRP sonar modules
- Sonar Command Center - view up to 4 independent sonar channels simultaneously
Video
- Monitor onboard video with support for up to 10 video of IP cameras and one analog camera
- View up to 4 cameras simultaneously
- Record and take snap shots of digital video streams
LightHouse II Software
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Raymarine's advanced HD Color signal processing with 256 color target discrimination
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Dual range mode and dual radar scanner (HD radar only)
- High speed 48rpm scanning (HD radar only)
Thermal Night Vision
- Stay safe with superior FLIR thermal night vision technology
- Easy-to-use. As simple as watching and controlling your TV
- Avoid obstacles, such as rocks, floating logs, and other debris
- Quickly identify overboard people and pets
- Slew-to-cue improves situational awareness and safety. Thermal camera automatically keeps "cued" targets in view at all times
Evolution Autopilot
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Follow waypoints and routes with unmatched precision using Evolution's aerospace derived 9-axis sensor technology
- Add a p70 or p70R pilot control head for remote control and advanced features
Engine Integration
- Complete monitoring of engines, generators, batteries and more
- NMEA 2000 compatible
- ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda and more
Digital Switching
- Control lighting, climate, navigation components, wipers, entertainment, security and much more
- State-of-the-art digital power distribution
Weather
- Stay ahead of the front with graphical weather overlays and weather reports from SIRIUSXM (USA only)
Networking- Network compatible with any LightHouse II powered multifunction display
- NMEA2000/SeaTalkng Port for NMEA2000 and SeaTalkng connections
- NMEA0183 Input/Output
- HDMI video output (eS9 and eS12 only)
- Wi-Fi for mobile app integration
- Bluetooth for remote and MP3 control
- Fusion Stereo control
Remote Control Options- RayControl Mobile App for iOS and Androids
- RMK-9 Wired Remote Keypad
- RCU-3 Bluetooth Wireless Remote
Specifications:
Cartography:Lighthouse, Navionics, C-MAP Essentials & C-MAP 4D MAX+
Tides & Currents:Requires Navionics or C-MAP
GPS Specs:Built-in GNSS Receiver: GPS/GLONASS/Beidou* - 10Hz 72 Channel. RS130 external GPS sensor option
Waypoints/Routes/Tracks:3,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 15 tracks - 10,000 max trk pts
Display Size:12.1" Optically Bonded LCD
Display Resolution:1280 x 800 WVGA
Display Type:Multitouch
Brightness:1,250 nits
Viewing Angle:Top / Bottom: 80 deg / 80 deg - Left / Right: 80 deg / 80 deg
Dimensions:14.1" x 8.8" x 2.6" (358mm x 223mm x 66mm)
Weight:TBD
Mounting:Flush / Bracket (R70389) / Rear (Rear Mt Accessory - A80343)
Waterproof Rating:IPX6/IPX7
Operating Temp:-13°F to 131°F (-25°C to +55°C)
Storage Temp:-22°F to 158°F (-30°C to +70°C)
Ethernet:2 x 10/100 Mbits/ Network (RayNet)
NMEA 0183: 2 Rx/1Tx NMEA0183 (On Power Cable)
NMEA 2000:1 x NMEA2000/SeaTalkng port
SeaTalk:Requires E22158 SeaTalk(1) to SeaTalkng convertor kit
Wi-FI:WiFi - 802.11 b/g
BlueTooth:Bluetooth 2.1 + EDR power class 1.5 (supports AVRCP 1.0)
Radar Capable: Yes
Thermal Night Vision Capable: Yes
Sonar Options - Built-In:Built-in 600W Digital Sonar
Transducers/Max Depth:50/200kHz 3,000'
External Sonar Module Capable:Yes Digital, CHIRP, and CHIRP SideVision Options
Memory Slot:Two MicroSD slots - up to 32GB each
Audio Integration:Fusion - Ethernet & N2K / Bluetooth / SiriusXM Audio
Video/Camera:1 x HDMI Video Out (5 meter accessory cable: A80219) 1 x Composite female BNC Input (On Power Cable) Up to 10 IP Cameras
Remote Control:RMK-9 & RCU-3
Weather:SiriusXM (Coastal) USA Only
AIS Capable:Yes
Autopilot Control:Yes - Evolution Autopilot Integration
Digital Switching:Yes - Empirbus compatible
Voltage:12V / 24V DC (10.8 V DC to 31.2V DC)
Power Consumption (Full Brightness):29.6W
Power Consumption (Powersave Mode):10WSpecifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics/C-Map
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Frequency: 50/200 khz
- Internal/External Antenna: Internal
- Resolution (VxH): 1280x800 WVGA
- Screen Size: 12.1'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Watts RMS - Max: 600w
- Waypoints/Routes: 3000/150
- Weather Capable: Yes
- Box Dimensions: 8"H x 11"W x 16"L WT: 14.3 lbs
- UPC: 723193797853
Brochure (pdf) - Network compatible with any LightHouse II powered multifunction display
Raymarine eS78 7" MFD Combo w/Wi-Fi, CHIRP/DownVision™ Sonar & Navionics+ North American Coast + 18k Lakes Charts
$1,299.99
eS78 7" MFD Chartplotter/Fishfinder Display with CHIRP/DownVision™ Sonar & Navionics+ North American Coast + 18k Lakes Charts
High Performance Multifunction Displays
Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Features:
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications:
- Screen Size: 7"
- Display size: 9.6" wide x 5.7" high
- Resolution: 800 x 480
- Built in CHIRP/DownVision™ Sonar
- Brightness: 1250 mits
- Voltage: 12V/24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x1)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes Navionics+ North America Coast and 18k Lake Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 3000/150
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: Color
- Screen Size: 7'
- Resolution (VxH): 800 x 480 WVGA
- Internal/External Antenna: Internal
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 9"H x 10"W x 13"L WT: 6.8 lbs
- UPC: 723193797174
Quick Guide (pdf)
Brochure (pdf)
Raymarine a127 12.1" MFD Combo w/Wi-FI - US Lake & Coastal Chart by C-MAP
$2,949.99
a127 Multifunction Touch Display with Built-In Digital Sonar
The a127 Multifunction Touch Display is the perfect all-in-one choice for cruising boats or coastal anglers. It combines all the GPS-chartplotter features of the a125, plus adds built-in, dual frequency (50/200 kHz) 600-watt digital sonar capable of targeting fish to depths of 3,000 feet. Add the compatible transducer of your choice (sold separately) to compete the system.
The a127 features a super-bright 12.1-inch sunlight viewable LCD screen with multitouch pinch-to-zoom control. Running Raymarine's LightHouse II user interface, it is a full featured GPS and chartplotter that is compatible with Navionics charts as well as LightHouse Raster and Vector charts of the USA or C-Map 4D.
Expand the a127's capabilities by connecting it to other Raymarine MFDs and accessories. The a127 features dual RayNet network ports for connecting to other displays, radar, sonar, thermal cameras, SiriusXM Marine Weather receivers and much more. The a127 is also SeaTalkng and NMEA2000 compatible for connecting to engines, instruments, Evolution autopilots and other network devices.
Fast and Responsive Chart Plotting
The a9 and a12 feature Raymarine's most advanced chartplotter engine with multitouch pinch-to-zoom. Every a9 and a12 also features:
- A built-in, 50-channel, 10 Hz GPS for fast and smooth vessel tracking
- GPS and Russian EGNOS support for faster acquisition and improved accuracy
- WAAS and EGNOS Satellite Based Augmentation System (SBAS) support for satellite differential corrections
- Optional external GA150 antenna for challenging below-deck applications
- Dual-slot MicroSD card reader with support for Raymarine LightHouse and Navionics charts and C-Map 4D
- Includes US Lakes and Coastal chart by C-Map provides over 12,900 US
Lakes with over 1,900 high-definition lake. Coastal navigation data
includes all critical navigation aids and chart objects, plus spot soundings
- US Lakes and Coastal Cruising data provided by Jeppesen is a subset of C-Map Max. Coastal data does not include Tides and Currents or C-Marina port database. The high-definition lakes data delivers 3 foot contour intervals or better
- Multitouch pinch-to-zoom
- Every Raymarine LightHouse II Multifunction display is compatible with Navionics+, Silver, Gold, Platinum+, HotMaps and HotMaps+ charts
Mobile Integration: Wireless is Built Right In
Every a9 and a12 display comes with standard Wi-Fi and Bluetooth wireless networking built-in. No external modules are accessory boxes are required. Pair you're a-Series with Raymarine's free apps for Apple and Android smartphones and tablets and enjoy the convenience of Raymarine Everywhere.
- Access aSeries anywhere onboard with Raymarine apps. No extra modules required
- Play and control MP3 audio on your smartphone remotely using Bluetooth
- Sync with the Navionics Boating app to exchange navigation data and even update charts!
- Navionics Plotter Sync bridges waypoints and routes between your aSeries and your smartphone or tablet
Your Sixth Sense at Sea: Video and Thermal Night Vision Integration
The a9 and a12 models both feature a standard composite video input port suitable for a marine camera or Raymarine Thermal Night Vision camera system using genuine FLIR infrared technology. Extend your boating day and navigate with confidence when you pair aSeries with any Raymarine T-Series camera.
- Thermal night vision meets touchscreen with aSeries and Raymarine thermal cameras
- Experience genuine FLIR thermal camera technology
- Choose fixed mount or pan/tilt/zoom thermal camera models
- Slew-to-Cue camera integration with AIS and Radar target
Raymarine aSeries also supports Video over IP, making it the perfect place to keep a watch of onboard safety and security. Connect multiple IP video cameras and use aSeries to view, record, playback and take video snapshots. Video camera are also great for monitoring remote spaces like engine rooms, or monitoring hard-to-see areas like side decks and cockpits.
Expand your aSeries Network with Radar and More!
Raymarine's a-Series are full-fledged network multifunction displays and work with our full line of Digital, HD Color and Super HD Color radar scanners. They also integrate seamlessly with other accessories like AIS, SiriusXM Marine Weather receivers, instruments, Evolution Autopilots, and much more. You can even customize your onboard navigation system by mixing and matching any combination of a-Series, c-Series, e-Series or gS-Series multifunction displays.
What's in the Box?
Every new a9 and a12 model includes these items in the box:
- Power/data/video cable (1.5 meters)
- Flexible Suncover
- Front trim bezel kit
- Trunnion bracket kit
- Flush mount kit
- SeaTalkng to Device Net Adapter (for connection to NMEA2000 networks)
- SeaTalkng Spur Cable (1-meter)
- RayNet to RayNet Interface Cable (2-meters)
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 5000/200
- Watts RMS - Max: 600W
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: Color
- Screen Size: 12.1'
- Resolution (VxH): 1280 x 800
- Internal/External Antenna: Internal
- Frequency: 50/200 khz
- Cartography Brand: C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 8"H x 15"W x 16"L WT: 15.9 lbs
- UPC: 723193794326
Raymarine a125 12.1" MFD w/Wi-Fi & Bluetooth - US LNC Vector Charts
$2,799.99
a125 Multifunction Touch Display
The a125 Multifunction Touch Display features a super-bright 12.1-inch sunlight viewable LCD screen with multitouch pinch-to-zoom control. Running Raymarine's LightHouse II user interface, it is a full featured GPS and chartplotter that is compatible with both Navionics charts as well as LightHouse Raster and Vector charts of the USA.
Expand the a125's capabilities by connecting it to other Raymarine MFDs and accessories. The a125 features dual RayNet network ports for connecting to other displays, radar, sonar, thermal cameras, SiriusXM Marine Weather receivers and much more. The a125 is also SeaTalkng and NMEA2000 compatible for connecting to engines, instruments, Evolution autopilots and other network devices.
Fast and Responsive Chart Plotting
The a9 and a12 feature Raymarine's most advanced chartplotter engine with multitouch pinch-to-zoom. Every a9 and a12 also features:
- A built-in, 50-channel, 10 Hz GPS for fast and smooth vessel tracking
- GPS and Russian EGNOS support for faster acquisition and improved accuracy
- WAAS and EGNOS Satellite Based Augmentation System (SBAS) support for satellite differential corrections
- Optional external GA150 antenna for challenging below-deck applications
- Dual-slot MicroSD card reader with support for both Raymarine LightHouse and Navionics charts
- Free raster and vector USA charts (available for free download on Raymarine.com)
- Multitouch pinch-to-zoom
- Every Raymarine LightHouse II Multifunction display is compatible with Navionics+, Silver, Gold, Platinum+, HotMaps and HotMaps+ charts
Mobile Integration: Wireless is Built Right In
Every a9 and a12 display comes with standard Wi-Fi and Bluetooth wireless networking built-in. No external modules are accessory boxes are required. Pair you're a-Series with Raymarine's free apps for Apple and Android smartphones and tablets and enjoy the convenience of Raymarine Everywhere.
- Access aSeries anywhere onboard with Raymarine apps. No extra modules required
- Play and control MP3 audio on your smartphone remotely using Bluetooth
- Sync with the Navionics Boating app to exchange navigation data and even update charts!
- Navionics Plotter Sync bridges waypoints and routes between your aSeries and your smartphone or tablet
Your Sixth Sense at Sea: Video and Thermal Night Vision Integration
The a9 and a12 models both feature a standard composite video input port suitable for a marine camera or Raymarine Thermal Night Vision camera system using genuine FLIR infrared technology. Extend your boating day and navigate with confidence when you pair aSeries with any Raymarine T-Series camera.
- Thermal night vision meets touchscreen with aSeries and Raymarine thermal cameras
- Experience genuine FLIR thermal camera technology
- Choose fixed mount or pan/tilt/zoom thermal camera models
- Slew-to-Cue camera integration with AIS and Radar target
Raymarine aSeries also supports Video over IP, making it the perfect place to keep a watch of onboard safety and security. Connect multiple IP video cameras and use aSeries to view, record, playback and take video snapshots. Video camera are also great for monitoring remote spaces like engine rooms, or monitoring hard-to-see areas like side decks and cockpits.
Expand your aSeries Network with Radar and More!
Raymarine's a-Series are full-fledged network multifunction displays and work with our full line of Digital, HD Color and Super HD Color radar scanners. They also integrate seamlessly with other accessories like AIS, SiriusXM Marine Weather receivers, instruments, Evolution Autopilots, and much more. You can even customize your onboard navigation system by mixing and matching any combination of a-Series, c-Series, e-Series or gS-Series multifunction displays.
What's in the Box?
Every new a9 and a12 model includes these items in the box:
- Power/data/video cable (1.5 meters)
- Flexible Suncover
- Front trim bezel kit
- Trunnion bracket kit
- Flush mount kit
- SeaTalkng to Device Net Adapter (for connection to NMEA2000 networks)
- SeaTalkng Spur Cable (1-meter)
- RayNet to RayNet Interface Cable (2-meters)
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics
- Cartography Type: Hotmaps/Silver/Gold/Platinum+
- Internal/External Antenna: Internal
- Resolution (VxH): 1280 x 800
- Screen Size: 12.1'
- Screen Type: Color
- Touchscreen: Yes
- Voltage - Input Range (Volts): 12/24VDC
- Waterproof Rating: Waterproof
- Waypoints/Routes: 5000/200
- Weather Capable: Yes
- Box Dimensions: 8"H x 15"W x 16"L WT: 15.4 lbs
- UPC: 723193790755
Brochure (pdf)
Raymarine a125 12.1" MFD w/Wi-Fi - US Lake & Coastal by C-MAP Chart
$2,849.99
a125 Multifunction Touch Display
The a125 Multifunction Touch Display features a super-bright 12.1-inch sunlight viewable LCD screen with multitouch pinch-to-zoom control. Running Raymarine's LightHouse II user interface, it is a full featured GPS and chartplotter that is compatible with both Navionics charts as well as C-Map 4D Charts.
Expand the a125's capabilities by connecting it to other Raymarine MFDs and accessories. The a125 features dual RayNet network ports for connecting to other displays, radar, sonar, thermal cameras, SiriusXM Marine Weather receivers and much more. The a125 is also SeaTalkng and NMEA2000 compatible for connecting to engines, instruments, Evolution autopilots and other network devices.
Fast and Responsive Chart Plotting
The a9 and a12 feature Raymarine's most advanced chartplotter engine with multitouch pinch-to-zoom. Every a9 and a12 also features:
- A built-in, 50-channel, 10 Hz GPS for fast and smooth vessel tracking
- GPS and Russian EGNOS support for faster acquisition and improved accuracy
- WAAS and EGNOS Satellite Based Augmentation System (SBAS) support for satellite differential corrections
- Optional external GA150 antenna for challenging below-deck applications
- Dual-slot MicroSD card reader with support for both Raymarine LightHouse and Navionics charts and C-Map 4D
- Includes US Lakes and Coastal chart by C-Map provides over 12,900 US
Lakes with over 1,900 high-definition lake. Coastal navigation data
includes all critical navigation aids and chart objects, plus spot soundings
and contours out to 60 feet or 20 meters
- US Lakes and Coastal Cruising data provided by Jeppesen is a subset of C-MAP MAX. Coastal data does not include Tides and Currents or C-Marina port
database. The high-definition lakes data delivers 3 foot contour intervals
or better
- Multitouch pinch-to-zoom
- Every Raymarine LightHouse II Multifunction display is compatible with Navionics+, Silver, Gold, Platinum+, HotMaps and HotMaps+ charts
Mobile Integration: Wireless is Built Right In
Every a9 and a12 display comes with standard Wi-Fi and Bluetooth wireless networking built-in. No external modules are accessory boxes are required. Pair you're a-Series with Raymarine's free apps for Apple and Android smartphones and tablets and enjoy the convenience of Raymarine Everywhere.
- Access aSeries anywhere onboard with Raymarine apps. No extra modules required
- Play and control MP3 audio on your smartphone remotely using Bluetooth
- Sync with the Navionics Boating app to exchange navigation data and even update charts!
- Navionics Plotter Sync bridges waypoints and routes between your aSeries and your smartphone or tablet
Your Sixth Sense at Sea: Video and Thermal Night Vision Integration
The a9 and a12 models both feature a standard composite video input port suitable for a marine camera or Raymarine Thermal Night Vision camera system using genuine FLIR infrared technology. Extend your boating day and navigate with confidence when you pair aSeries with any Raymarine T-Series camera.
- Thermal night vision meets touchscreen with aSeries and Raymarine thermal cameras
- Experience genuine FLIR thermal camera technology
- Choose fixed mount or pan/tilt/zoom thermal camera models
- Slew-to-Cue camera integration with AIS and Radar target
Raymarine aSeries also supports Video over IP, making it the perfect place to keep a watch of onboard safety and security. Connect multiple IP video cameras and use aSeries to view, record, playback and take video snapshots. Video camera are also great for monitoring remote spaces like engine rooms, or monitoring hard-to-see areas like side decks and cockpits.
Expand your aSeries Network with Radar and More!
Raymarine's a-Series are full-fledged network multifunction displays and work with our full line of Digital, HD Color and Super HD Color radar scanners. They also integrate seamlessly with other accessories like AIS, SiriusXM Marine Weather receivers, instruments, Evolution Autopilots, and much more. You can even customize your onboard navigation system by mixing and matching any combination of a-Series, c-Series, e-Series or gS-Series multifunction displays.
What's in the Box?
Every new a9 and a12 model includes these items in the box:
- Power/data/video cable (1.5 meters)
- Flexible Suncover
- Front trim bezel kit
- Trunnion bracket kit
- Flush mount kit
- SeaTalkng to Device Net Adapter (for connection to NMEA2000 networks)
- SeaTalkng Spur Cable (1-meter)
- RayNet to RayNet Interface Cable (2-meters)
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 5000/200
- Waterproof Rating: Waterproof
- Voltage - Input Range (Volts): 12/24VDC
- Touchscreen: Yes
- Screen Type: Color
- Screen Size: 12.1'
- Resolution (VxH): 1280 x 800
- Internal/External Antenna: Internal
- Cartography Brand: C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 8"H x 15"W x 16"L WT: 15.5 lbs
- UPC: 723193794319
Raymarine EV-200 Power Hydraulic Evolution Autopilot
$2,899.99
EV-200 Power Hydraulic Evolution Autopilot
Features:
- A complete autopilot-in-a-box
- Evolution Ai for superior performance
- No calibration required
- Includes Type 1 Hydraulic Drive Unit
- SeaTalkng Network Compatible
- ACU-200 auxiliary power to SeaTalkng network
- Includes p70R Autopilot Controller
Includes:
- EV-1 Sensor Core
- p70R Autopilot Control Head
- ACU-200 Actuator Control Unit (Includes the M81105 Rotary Rudder Reference)
- Type 1 Hydraulic Pump
- Evolution Cabling Kit
- EV Unit O-Ring Pack (set of 2)
- Wall Mounting Bracket
The EV Sensor Core
At the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.
Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.
The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkngand NMEA2000 networks.
Features:
- Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change
- Flexible installation options
- Mount above or below deck
- Simple SeaTalkng connectivity to the control head and ACU
- Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions
- Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays
p70R Autopilot Control Head
The p70R has a convenient rotary control knob and support for multiple autopilot modes including Auto, standby, trolling patterns, and track mode from your GPS or chartplotter.
Features:
- LightHouse user interface is simple and quick to use
- Wide 160° viewing angles
- Start up wizard helps you configure the pilot quickly and easily
- Anti-reflective coating for improved visibility in bright sunlight
- Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness
- Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer
- Simple system and group dimming/illumination
- Support for multiple data sources
- SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required)
ACU-200 Autopilot Control Unit (ACU)
The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.
Type 1 Hydraulic Pump
The reversing 12V hydraulic pump is for use with steering systems equipped with 4.914 cubic inch (80cc - 230cc) hydraulic steering rams. The Type 1 hydraulic drive is compatible with both S1/S1G and S2/S2G corepacks.
Evolution Cabling Kit
- 1 x SeaTalkng Power Cable (0.4m)
- 1 x SeaTalkng Backbone Cable (5m)
- 1 x SeaTalkng Spur Cable (0.4m)
- 1 x SeaTalkng 5-way Connector Block
- 2 x SeaTalkng T-piece Connector
- 2 x SeaTalkng Terminator
Specifications:
- Drive Type: Hydraulic
- Box Dimensions: 8"H x 17"W x 21"L WT: 18.75 lbs
Quick Guide (pdf)
Brochure (pdf)
Raymarine EV-200 Sail Evolution Autopilot
$1,999.99
EV-200 Sail Evolution Autopilot
Features:
- Evolution Ai for superior performance
- No calibration required
- Use with any Type 1 Linear or Rotary Drive Unit (sold separately)
- 12V or 24V DC operation
- SeaTalkng Network Compatible
- ACU-200 auxiliary power to SeaTalkng network
- Includes p70 Autopilot Controller
Includes:
- EV-1 Sensor Core
- p70s Autopilot Control Head
- ACU-200 Actuator Control Unit (Includes the M81105 Rotary Rudder Reference)
- Evolution Cabling Kit
- EV Unit O-Ring Pack (set of 2)
- Wall Mounting Bracket
The EV Sensor Core
At the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.
Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.
The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkng and NMEA2000 networks.
Features:
- Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change
- Flexible installation options
- Mount above or below deck
- Simple SeaTalkng connectivity to the control head and ACU
- Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions
- Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays
p70s Autopilot Control Head
The p70s is a push-button operation controller designed primarily for sailboats.
Superior Viewing
Advanced LED backlighting offers low power consumption and delivers vibrant color and contrast. Wide horizontal and vertical viewing angles ensure the display can be seen clearly from acute positions.
Features:
- LightHouse user interface is simple and quick to use
- Wide 160° viewing angles
- Start up wizard helps you configure the pilot quickly and easily
- Anti-reflective coating for improved visibility in bright sunlight
- Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness
- Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer
- Simple system and group dimming/illumination
- Support for multiple data sources
- SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required)
ACU-200 Autopilot Control Unit (ACU)
The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.
Supported Drive Units
Type 1 Linear or Rotary Drive Units (sold separately)
Evolution Cabling Kit
- 1 x SeaTalkng Power Cable (0.4m)
- 1 x SeaTalkng Backbone Cable (5m)
- 1 x SeaTalkng Spur Cable (0.4m)
- 1 x SeaTalkng 5-way Connector Block
- 2 x SeaTalkng T-piece Connector
- 2 x SeaTalkng Terminator
Specifications:
- Box Dimensions: 8"H x 17"W x 21"L WT: 13.1 lbs
- UPC: 723193774298
Quick Guide (pdf)
Brochure (pdf)
Raymarine 12kW HD Pedestal w/VCM100 Voltage Converter
$4,849.99
12kW HD Pedestal with VCM100 Voltage Converter
Raymarine's HD Digital technology brings radar users the power of digital signal processing with a truly adaptive transmitter and receiver that automatically adjusts to changing environmental and sea conditions. HD Digital radar delivers a dramatically clearer radar picture with crisp, well-defined contact echoes and life-like target presentation.
Specifications:
- Power - Output (Kilowatts): 12kW
- Box Dimensions: 18"H x 17"W x 21"L WT: 52.55 lbs
- UPC: 091975008948
Raymarine 1M Spur Cable f/SeaTalkng
$29.99
Spur Cable
Raymarine 1 meter Spur Cable for SeaTalkng
Specifications:
- Box Dimensions: 1"H x 6"W x 7"L WT: 0.05 lbs
- UPC: 723193060391
Raymarine 25M Digital Radar Cable w/RayNet Connector On One End
$319.99
25M Digital Radar Cable w/ Raynet Connector f/HD & Super HD Color Radar Scanners
Raymarine 3M Backbone Cable f/SeaTalkng
$34.99
Backbone Cables
In a SeaTalkng installation, a backbone cable runs through the length of the boat.
Individual devices connect to the backbone by spur cables that run to T-pieces on the backbone. The backbone carries both data and power to attached devices. The backbone should be sized so that it will run past every location where an NG or NMEA 2000 device might be installed.
Two backbone cable lengths can be joined together by part A06030, a backbone extender.
Specifications:
- Box Dimensions: 1"H x 7"W x 7"L WT: 0.35 lbs
- UPC: 723193060353
Raymarine 3M Spur Cable f/SeaTalkng
$34.99
Spur Cable
Raymarine 3 meter Spur Cable for SeaTalkng
Specifications:
- Box Dimensions: 1"H x 7"W x 8"L WT: 0.5 lbs
- UPC: 723193060407
Raymarine 400MM Spur Cable f/SeaTalkng
$24.99
Spur Cable
Raymarine 400MM Spur Cable for SeaTalkng
Specifications:
- Box Dimensions: 1"H x 6"W x 7"L WT: 0.05 lbs
- UPC: 723193060384
Raymarine 48" HD Digital Open Array
$749.99
48" HD Digital Open Array
Truly revolutionary, Raymarine HD Color technology improves target detection by eliminating virtually all noise and extracting more information from the radar echo return than has ever been generally available to the leisure navigator before.
Features:
- HD Color technology delivers superior processing and target detection
- Multi-level color target displays
- Adaptive auto settings
- Coastal, Harbor, Offshore and Buoy Auto modes
- SeaTalkHS network compatible
- Thin radar interconnect assembly
- Simple install, no need to open pedestal (external waterproof connector)
- 10.8 to 32V DC operation with supplied external voltage converter
- Field upgradeable software via CF card in GPM400
- HD Color Radar technology maximizes digital radar receiver performance, enabling 4kW Raymarine radars to deliver target detection that rivals much larger and more powerful analogue radar systems
- Raymarine HD Color technology improves target detection by 100% digital signal precessing and information extraction
- HD Color radar technology delivers substantial improvements in range and bearing resolution
Specifications:
- Array Size (Inches): 48'
- Box Dimensions: 9"H x 12"W x 54"L WT: 20.1 lbs
- UPC: 723193520833
Raymarine 48" Super HD Digital Open Array
$749.99
48" Super HD Digital Open Array
Super HD Color adds another level of digital signal processing to futher enhance the performance and improve the resolution. Stunning multi-level color target displays provide extra clarity and detail.
Features:
- HD Color technology delivers superior processing and target detection
- Multi-level color target displays
- Adaptive auto settings
- Coastal, Harbor, Offshore and Buoy Auto modes
- SeaTalkHS network compatible
- Thin radar interconnect assembly
- Simple install, no need to open pedestal (external waterproof connector)
- 10.8 to 32V DC operation with supplied external voltage converter
- Field upgradeable software via CF card in GPM400
- HD Color Radar technology maximizes digital radar receiver performance, enabling 4kW Raymarine radars to deliver target detection that rivals much larger and more powerful analogue radar systems
- Raymarine HD Color technology improves target detection by 100% digital signal precessing and information extraction
- Super HD Color radar technology delivers substantial improvements in range and bearing resolution
Specifications:
- Array Size (Inches): 48'
- Box Dimensions: 9"H x 11"W x 54"L WT: 20.7 lbs
- UPC: 723193520925
Raymarine 4kW HD Digital Pedestal
$3,049.99
4kW HD Digital Pedestal
Raymarine's HD Digital technology brings radar users the power of digital signal processing with a truly adaptive transmitter and receiver that automatically adjusts to changing environmental and sea conditions. HD Digital radar delivers a dramatically clearer radar picture with crisp, well-defined contact echoes and life-like target presentation.
Specifications:
- Power - Output (Kilowatts): 4kW
- Box Dimensions: 17"H x 18"W x 21"L WT: 53 lbs
- UPC: 723193520949
Raymarine 4kW Super HD Digital Pedestal
$4,049.99
4kW Super HD Digital Pedestal
Raymarine's Super HD Digital technology brings radar users the power of digital signal processing with a truly adaptive transmitter and receiver that automatically adjusts to changing environmental and sea conditions. Super HD Digital radar delivers a dramatically clearer radar picture with crisp, well-defined contact echoes and life-like target presentation.
Specifications:
- Power - Output (Kilowatts): 4kW
- Box Dimensions: 17"H x 18"W x 21"L WT: 53.45 lbs
- UPC: 723193520819
Raymarine 5M Spur Cable f/SeaTalkng
$44.99
Spur Cable
Raymarine 5 meter Spur Cable for SeaTalkng
Specifications:
- Box Dimensions: 1"H x 5"W x 6"L WT: 0.4 lbs
- UPC: 723193060414
Raymarine A102138 P58 Transom Mount Tri-Ducer
$99.99
Compatible with the following sounders:
- DSM25
- A50D
- A57D
- A70D
- a67, a77
- c97, c127
- e97, e127
Compatible hull material: aluminum, wood, and fiberglass
Frequency: 200/50 kHz
Cable: 25ft cable
Specifications:
- Cable Length (Feet): 25'
- Frequency: 200/50
- Mounting Style: Transom
- Speed Included: Yes
- Temperature: Yes
- Box Dimensions: 1"H x 6"W x 8"L WT: 1.9 lbs
- UPC: 091975004377
Raymarine a75 Wi-Fi 7" MFD Touchscreen - Lighthouse Navigation Charts - NOAA Vector
$849.99
a75 Wi-Fi 7" MFD Touchscreen - Lighthouse Navigation Charts - NOAA Vector
Raymarine's a75 Wi-Fi Multifunction Touch Display is a full-featured multifunction display with a built-in GPS receiver and Navionics compatible chartplotter. The a75 Wi-Fi also features standard wireless networking so you can see and control your a75 from your Smartphone and Tablet using Raymarine mobile apps.
The a75 Wi-Fi can be expanded to include radar, sonar, CHIRP DownVision™, weather, AIS, and much, much more.
Features:
- Swipe, touch and navigate - the a75 is powered by Raymarine's intuitive LightHouse™ User Interface
- Super-bright 7", optically bonded touchscreen with LED backlighting
- Super-fast, dual core processor plus a dedicated graphics processor
- Built-in Wi-Fi wireless networking
- Control your a75 Wi-Fi from popular Smartphones or Tablets
- Built-in 50-channel GPS receiver
- Includes NOAA Vector Chart
- Compatible with Navionics Silver, Gold, Platinum or HotMaps Charts on microSD
- RayNet (Ethernet) port for radar, weather and networking with Raymarine MFDs
- FUSION Audio integration - Full of control for FUSION 700 series marine stereos
- SiriusXM weather and satellite radio compatible using optional SR150 receiver
- NMEA2000 compatible SeaTalkng port for engine, instruments and Raymarine autopilot integration
- Monitor your fuel consumption with on screen fuel range overlays and fuel manager
- Video-over-IP support for networked cameras with video playback and record
- Built-in Bluetooth wireless connection for optional media playback or remote control
- Bracket and console mounting hardware included
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics
- Cartography Type: Hotmaps/Silver/Gold/Platinum+
- Internal/External Antenna: Internal
- Resolution (VxH): 800 x 480
- Screen Size: 7'
- Screen Type: Color
- Touchscreen: Yes
- Waterproof Rating: Waterproof
- Waypoints/Routes: 5000/200
- Weather Capable: Yes
- Box Dimensions: 6"H x 11"W x 11"L WT: 4.9 lbs
- UPC: 723193788363
Brochure (pdf)
Raymarine a78 Wi-Fi 7" MFD w/CHIRP Downvison™, ClearPulse™ & CPT-100 US Lakes & Coastal Chart by C-MAP
$999.99
a78 Wi-Fi 7" MFD Touchscreen w/CHIRP DownVision™, ClearPulse™ & CPT-100 - US Lakes & Coastal Chart by C-MAP
Raymarine's a78 Wi-Fi is a full-featured multifunction display with CHIRP DownVision™ Sonar technology built in. The a78 Wi-Fi also features standard wireless networking so you can see and control the a78 from your Smartphone and Tablet using Raymarine mobile apps.
The dual channel sonar in the a78 Wi-Fi lets you see fish and bottom structure like never before, it's like having two sonars in one! The a78 Wi-Fi's CHIRP DownVision™ channel delivers stunning images of underwater structure, fish, wrecks and more with photo-like clarity. The a78 Wi-Fi also features a CHIRP fish targeting channel for easy identification of baitfish and predators.
Features:
- Swipe, touch and navigate - the a78 is powered by Raymarine's intuitive LightHouse™ User Interface
- Super fast, dual core processor plus a dedicated graphics processor
- Built-in Wi-Fi wireless networking
- Control your a78 from popular Smartphones or Tablets
- Dual Channel sonar with both CHIRP DownVision™ and CHIRP Fish Targeting sonar imagery to depths of 600 feet
- Super-bright 7", optically bonded touchscreen with LED backlighting
- Built-in 50-channel GPS receiver
- Includes US Lakes and Coastal (-US) chart bundle provides over 12,900
US Lakes with over 1,900 high-definition lake. Coastal navigation data
includes all critical navigation aids and chart objects, plus spot soundings
and contours out to 60 feet or 20 meters
US Lakes and Coastal Cruising data provided by Jeppesen is a subset of
C-MAP MAX. Coastal data does not include Tides and Currents or C-Marina
port database. The high-definition lakes data delivers 3 foot contour
intervals or better
- Compatible with Navionics Silver, Gold, Platinum or HotMaps Charts and C-Map 4d on MicroSD
- RayNet (Ethernet) port for radar, weather and networking with Raymarine MFDs
- FUSION Audio integration - Full of control for FUSION 700 series marine stereos
- SiriusXM weather and satellite radio compatible using optional SR150 receiver
- NMEA2000 compatible SeaTalkng port for engine, instruments and Raymarine autopilot integration
- Monitor your fuel consumption with on screen fuel range overlays and fuel manager
- Video-over-IP support for networked cameras with video playback and record
- Built-in Bluetooth wireless connection for optional media playback or remote control
- CPT-100 transom mount transducer with temperature sensor included
- Bracket and console mounting hardware included
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 5000/200
- Waterproof Rating: Waterproof
- Transducer Type: Transom Mount
- Touchscreen: Yes
- Speed/Temp: Temp Only
- Screen Type: Color
- Screen Size: 7'
- Resolution (VxH): 840 x 480
- Internal/External Antenna: Internal
- Included Transducer: CPT-100
- Cartography Type: C-Map 4D
- Cartography Brand: C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 7"H x 12"W x 15"L WT: 8.4 lbs
- UPC: 723193794272
Raymarine a78 Wi-Fi 7" MFD w/CHIRP Downvison™, ClearPulse™ & CPT-100 - Navionics North America Gold
$1,099.99
a78 Wi-Fi 7" MFD Touchscreen w/CHIRP DownVision™, ClearPulse™ & CPT-100 - Navionics North America Gold Chart
Raymarine's a78 Wi-Fi is a full-featured multifunction display with CHIRP DownVision™ Sonar technology built in. The a78 Wi-Fi also features standard wireless networking so you can see and control the a78 from your Smartphone and Tablet using Raymarine mobile apps.
The dual channel sonar in the a78 Wi-Fi lets you see fish and bottom structure like never before, it's like having two sonars in one! The a78 Wi-Fi's CHIRP DownVision™ channel delivers stunning images of underwater structure, fish, wrecks and more with photo-like clarity. The a78 Wi-Fi also features a CHIRP fish targeting channel for easy identification of baitfish and predators.
Features:
- Swipe, touch and navigate - the a78 is powered by Raymarine's intuitive LightHouse™ User Interface
- Super fast, dual core processor plus a dedicated graphics processor
- Built-in Wi-Fi wireless networking
- Control your a78 from popular Smartphones or Tablets
- Dual Channel sonar with both CHIRP DownVision™ and CHIRP Fish Targeting sonar imagery to depths of 600 feet
- Super-bright 7", optically bonded touchscreen with LED backlighting
- Built-in 50-channel GPS receiver
- Includes Navionics North America Gold
- Compatible with Navionics Silver, Gold, Platinum or HotMaps Charts on MicroSD
- RayNet (Ethernet) port for radar, weather and networking with Raymarine MFDs
- FUSION Audio integration - Full of control for FUSION 700 series marine stereos
- SiriusXM weather and satellite radio compatible using optional SR150 receiver
- NMEA2000 compatible SeaTalkng port for engine, instruments and Raymarine autopilot integration
- Monitor your fuel consumption with on screen fuel range overlays and fuel manager
- Video-over-IP support for networked cameras with video playback and record
- Built-in Bluetooth wireless connection for optional media playback or remote control
- CPT-100 transom mount transducer with temperature sensor included
- Bracket and console mounting hardware included
Specifications:
- Weather Capable: Yes
- Transducer Type: Transom Mount
- Touchscreen: Yes
- Speed/Temp: Temp Only
- Screen Type: Color
- Screen Size: 7'
- Resolution (VxH): 840 x 480
- Internal/External Antenna: Internal
- Included Transducer: CPT-100
- Cartography Type: Gold
- Cartography Brand: Navionics
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Waypoints/Routes: 5000/200
- Waterproof Rating: Waterproof
- Box Dimensions: 6"H x 12"W x 15"L WT: 8.3 lbs
- UPC: 723193793633
Raymarine a97 9" MFD Combo w/Wi-Fi & Bluetooth - US LNC Vector Charts
$1,449.99
a97 Multifunction Touch Display with Built-In Digital Sonar
The a97 Multifunction Touch Display is the perfect all-in-one choice for cruising boats or coastal anglers. It combines all the GPS-chartplotter features of the a95, plus adds built-in, dual frequency (50/200 kHz) 600-watt digital sonar capable of targeting fish to depths of 3,000 feet. Add the compatible transducer of your choice (sold separately) to compete the system.
The a97 features a super-bright 9-inch sunlight viewable LCD screen with multitouch pinch-to-zoom control. Running Raymarine's LightHouse II user interface, it is a full featured GPS and chartplotter that is compatible with both Navionics charts as well as LightHouse Raster and Vector charts of the USA.
Expand the a97's capabilities by connecting it to other Raymarine MFDs and accessories. The a97 features dual RayNet network ports for connecting to other displays, radar, sonar, thermal cameras, SiriusXM Marine Weather receivers and much more. The a95 is also SeaTalkng and NMEA2000 compatible for connecting to engines, instruments, Evolution autopilots and other network devices.
Fast and Responsive Chart Plotting
The a9 and a12 feature Raymarine's most advanced chartplotter engine with multitouch pinch-to-zoom. Every a9 and a12 also features:
- A built-in, 50-channel, 10 Hz GPS for fast and smooth vessel tracking
- GPS and Russian EGNOS support for faster acquisition and improved accuracy
- WAAS and EGNOS Satellite Based Augmentation System (SBAS) support for satellite differential corrections
- Optional external GA150 antenna for challenging below-deck applications
- Dual-slot MicroSD card reader with support for both Raymarine LightHouse and Navionics charts
- Free raster and vector USA charts (available for free download on Raymarine.com)
- Multitouch pinch-to-zoom
- Every Raymarine LightHouse II Multifunction display is compatible with Navionics+, Silver, Gold, Platinum+, HotMaps and HotMaps+ charts
Mobile Integration: Wireless is Built Right In
Every a9 and a12 display comes with standard Wi-Fi and Bluetooth wireless networking built-in. No external modules are accessory boxes are required. UPair you're a-Series with Raymarine's free apps for Apple and Android smartphones and tablets and enjoy the convenience of Raymarine Everywhere.
- Access aSeries anywhere onboard with Raymarine apps. No extra modules required
- Play and control MP3 audio on your smartphone remotely using Bluetooth
- Sync with the Navionics Boating app to exchange navigation data and even eupdate charts!
- Navionics Plotter Sync bridges waypoints and routes between your aSeries and your smartphone or tablet
Your Sixth Sense at Sea: Video and Thermal Night Vision Integration
The a9 and a12 models both feature a standard composite video input port suitable for a marine camera or Raymarine Thermal Night Vision camera system using genuine FLIR infrared technology. Extend your boating day and navigate with confidence when you pair aSeries with any Raymarine T-Series camera.
- Thermal night vision meets touchscreen with aSeries and Raymarine thermal cameras
- Experience genuine FLIR thermal camera technology
- Choose fixed mount or pan/tilt/zoom thermal camera models
- Slew-to-Cue camera integration with AIS and Radar target
Raymarine aSeries also supports Video over IP, making it the perfect place to keep a watch of onboard safety and security. Connect multiple IP video cameras and use aSeries to view, record, playback and take video snapshots. Video camera are also great for monitoring remote spaces like engine rooms, or monitoring hard-to-see areas like side decks and cockpits.
Expand your aSeries Network with Radar and More!
Raymarine's a-Series are full-fledged network multifunction displays and work with our full line of Digital, HD Color and Super HD Color radar scanners. They also integrate seamlessly with other accessories like AIS, SiriusXM Marine Weather receivers, instruments, Evolution Autopilots, and much more. You can even customize your onboard navigation system by mixing and matching any combination of a-Series, c-Series, e-Series or gS-Series multifunction displays.
What's in the Box?
Every new a9 and a12 model includes these items in the box:
- Power/data/video cable (1.5 meters)
- Flexible Suncover
- Front trim bezel kit
- Trunnion bracket kit
- Flush mount kit
- SeaTalkng to Device Net Adapter (for connection to NMEA2000 networks)
- SeaTalkng Spur Cable (1-meter)
- RayNet to RayNet Interface Cable (2-meters)
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics
- Cartography Type: Hotmaps/Silver/Gold/Platinum+
- Frequency: 50/200 khz
- Included Transducer: No
- Internal/External Antenna: Internal
- Resolution (VxH): 800 x 480
- Screen Size: 9'
- Screen Type: Color
- Speed/Temp: Optional
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Watts RMS - Max: 600W
- Waypoints/Routes: 3,000/200
- Weather Capable: Yes
- Box Dimensions: 7"H x 14"W x 13"L WT: 11.05 lbs
- UPC: 723193790670
Brochure (pdf)
Raymarine a98 9" MFD Combo w/Wi-Fi, Bluetooth & CHIRP DownVision™ - US LNC Vector Charts
$1,449.99
a98 Multifunction Touch Display with Built-In CHIRP DownVision Sonar
The a98 Multifunction Touch Display enables serious freshwater and inshore anglers to experience Visionality with its built-in CHIRP DownVision Sonar. The a98 is actually 2 sonars in one because it features 2 discrete CHIRP channels. CHIRP DownVision delivers stunning underwater views of bottom, structure and fish while the CHIRP fish targeting channel makes easy work of identifying both bait and game fish. Add the CHIRP DownVision transducer of your choice (sold separately) to complete the system.
The a98 features a super-bright 9-inch sunlight viewable LCD screen with multitouch pinch-to-zoom control. Running Raymarine's LightHouse II user interface, it is a full featured GPS and chartplotter that is compatible with both Navionics charts as well as LightHouse Raster and Vector charts of the USA.
Expand the a98's capabilities by connecting it to other Raymarine MFDs and accessories. The a98 features dual RayNet network ports for connecting to other displays, radar, sonar, thermal cameras, SiriusXM Marine Weather receivers and much more. The a98 is also SeaTalkng and NMEA2000 compatible for connecting to engines, instruments, Evolution autopilots and other network devices.
Fast and Responsive Chart Plotting
The a9 and a12 feature Raymarine's most advanced chartplotter engine with multitouch pinch-to-zoom. Every a9 and a12 also features:
- A built-in, 50-channel, 10 Hz GPS for fast and smooth vessel tracking
- GPS and Russian EGNOS support for faster acquisition and improved accuracy
- WAAS and EGNOS Satellite Based Augmentation System (SBAS) support for satellite differential corrections
- Optional external GA150 antenna for challenging below-deck applications
- Dual-slot MicroSD card reader with support for both Raymarine LightHouse and Navionics charts
- Free raster and vector USA charts (available for free download on Raymarine.com)
- Multitouch pinch-to-zoom
- Every Raymarine LightHouse II Multifunction display is compatible with Navionics+, Silver, Gold, Platinum+, HotMaps and HotMaps+ charts
=
Mobile Integration: Wireless is Built Right In
Every a9 and a12 display comes with standard Wi-Fi and Bluetooth wireless networking built-in. No external modules are accessory boxes are required. Pair you're a-Series with Raymarine's free apps for Apple and Android smartphones and tablets and enjoy the convenience of Raymarine Everywhere.
- Access aSeries anywhere onboard with Raymarine apps. No extra modules required
- Play and control MP3 audio on your smartphone remotely using Bluetooth
- Sync with the Navionics Boating app to exchange navigation data and even update charts!
- Navionics Plotter Sync bridges waypoints and routes between your aSeries and your smartphone or tablet
Your Sixth Sense at Sea: Video and Thermal Night Vision Integration
The a9 and a12 models both feature a standard composite video input port suitable for a marine camera or Raymarine Thermal Night Vision camera system using genuine FLIR infrared technology. Extend your boating day and navigate with confidence when you pair aSeries with any Raymarine T-Series camera.
- Thermal night vision meets touchscreen with aSeries and Raymarine thermal cameras
- Experience genuine FLIR thermal camera technology
- Choose fixed mount or pan/tilt/zoom thermal camera models
- Slew-to-Cue camera integration with AIS and Radar target
Raymarine aSeries also supports Video over IP, making it the perfect place to keep a watch of onboard safety and security. Connect multiple IP video cameras and use aSeries to view, record, playback and take video snapshots. Video camera are also great for monitoring remote spaces like engine rooms, or monitoring hard-to-see areas like side decks and cockpits.
Expand your aSeries Network with Radar and More!
Raymarine's a-Series are full-fledged network multifunction displays and work with our full line of Digital, HD Color and Super HD Color radar scanners. They also integrate seamlessly with other accessories like AIS, SiriusXM Marine Weather receivers, instruments, Evolution Autopilots, and much more. You can even customize your onboard navigation system by mixing and matching any combination of a-Series, c-Series, e-Series or gS-Series multifunction displays.
What's in the Box?
Every new a9 and a12 model includes these items in the box:
- Power/data/video cable (1.5 meters)
- Flexible Suncover
- Front trim bezel kit
- Trunnion bracket kit
- Flush mount kit
- SeaTalkng to Device Net Adapter (for connection to NMEA2000 networks)
- SeaTalkng Spur Cable (1-meter)
- RayNet to RayNet Interface Cable (2-meters)
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics
- Cartography Type: Hotmaps/Silver/Gold/Platinum+
- Included Transducer: No
- Internal/External Antenna: Internal
- Resolution (VxH): 800 x 480
- Screen Size: 9'
- Screen Type: Color
- Speed/Temp: Optional
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Watts RMS - Max: 600w
- Waypoints/Routes: 3,000/200
- Weather Capable: Yes
- Box Dimensions: 7"H x 14"W x 13"L WT: 10.95 lbs
- UPC: 723193790717
Brochure (pdf)
Raymarine a98 9" MFD Combo w/Wi-Fi, CHIRP DownVision CPT-100 Transducer - US Lake & Coastal Chart by C-MAP
$1,549.99
a98 Multifunction Touch Display with Built-In CHIRP DownVision Sonar- US Lake and Coastal Chart by C-Map
The a98 Multifunction Touch Display enables serious freshwater and inshore anglers to experience Visionality with its built-in CHIRP DownVision Sonar. The a98 is actually 2 sonars in one because it features 2 discrete CHIRP channels. CHIRP DownVision delivers stunning underwater views of bottom, structure and fish while the CHIRP fish targeting channel makes easy work of identifying both bait and game fish.
Comes with the CPT-100 CHIRP/DownVision Transom Mount Transducer.
The a98 features a super-bright 9-inch sunlight viewable LCD screen with multitouch pinch-to-zoom control. Running Raymarine's LightHouse II user interface, it is a full featured GPS and chartplotter that is compatible with both Navionics charts as well C-Map 4D.
Expand the a98's capabilities by connecting it to other Raymarine MFDs and accessories. The a98 features dual RayNet network ports for connecting to other displays, radar, sonar, thermal cameras, SiriusXM Marine Weather receivers and much more. The a98 is also SeaTalkng and NMEA2000 compatible for connecting to engines, instruments, Evolution autopilots and other network devices.
Fast and Responsive Chart Plotting
The a9 and a12 feature Raymarine's most advanced chartplotter engine with multitouch pinch-to-zoom. Every a9 and a12 also features:
- A built-in, 50-channel, 10 Hz GPS for fast and smooth vessel tracking
- GPS and Russian EGNOS support for faster acquisition and improved accuracy
- WAAS and EGNOS Satellite Based Augmentation System (SBAS) support for satellite differential corrections
- Optional external GA150 antenna for challenging below-deck applications
- Dual-slot MicroSD card reader with support for both Raymarine LightHouse and Navionics charts and C-Map 4D
- Includes US Lakes and Coastal chart by C-Map provides over 12,900 US Lakes with over 1,900 high-definition lake. Coastal navigation data includes all critical navigation aids and chart objects, plus spot soundings and contours out to 60 feet or 20 meters
- US Lakes and Coastal Cruising data provided by Jeppesen is a subset of C-MAP MAX. Coastal data does not include Tides and Currents or C-Marina port database. The high-definition lakes data delivers 3 foot contour intervals or better
- Multitouch pinch-to-zoom
- Every Raymarine LightHouse II Multifunction display is compatible with Navionics+, Silver, Gold, Platinum+, HotMaps and HotMaps+ charts
Mobile Integration: Wireless is Built Right In
Every a9 and a12 display comes with standard Wi-Fi and Bluetooth wireless networking built-in. No external modules are accessory boxes are required. Pair you're a-Series with Raymarine's free apps for Apple and Android smartphones and tablets and enjoy the convenience of Raymarine Everywhere.
- Access aSeries anywhere onboard with Raymarine apps. No extra modules required
- Play and control MP3 audio on your smartphone remotely using Bluetooth
- Sync with the Navionics Boating app to exchange navigation data and even update charts!
- Navionics Plotter Sync bridges waypoints and routes between your aSeries and your smartphone or tablet
Your Sixth Sense at Sea: Video and Thermal Night Vision Integration
The a9 and a12 models both feature a standard composite video input port suitable for a marine camera or Raymarine Thermal Night Vision camera system using genuine FLIR infrared technology. Extend your boating day and navigate with confidence when you pair aSeries with any Raymarine T-Series camera.
- Thermal night vision meets touchscreen with aSeries and Raymarine thermal cameras
- Experience genuine FLIR thermal camera technology
- Choose fixed mount or pan/tilt/zoom thermal camera models
- Slew-to-Cue camera integration with AIS and Radar target
Raymarine aSeries also supports Video over IP, making it the perfect place to keep a watch of onboard safety and security. Connect multiple IP video cameras and use aSeries to view, record, playback and take video snapshots. Video camera are also great for monitoring remote spaces like engine rooms, or monitoring hard-to-see areas like side decks and cockpits.
Expand your aSeries Network with Radar and More!
Raymarine's a-Series are full-fledged network multifunction displays and work with our full line of Digital, HD Color and Super HD Color radar scanners. They also integrate seamlessly with other accessories like AIS, SiriusXM Marine Weather receivers, instruments, Evolution Autopilots, and much more. You can even customize your onboard navigation system by mixing and matching any combination of a-Series, c-Series, e-Series or gS-Series multifunction displays.
What's in the Box?
Every new a9 and a12 model includes these items in the box:
- Power/data/video cable (1.5 meters)
- CPT-100 Transom Mount Transducer
- Flexible Suncover
- Front trim bezel kit
- Trunnion bracket kit
- Flush mount kit
- SeaTalkng to Device Net Adapter (for connection to NMEA2000 networks)
- SeaTalkng Spur Cable (1-meter)
- RayNet to RayNet Interface Cable (2-meters)
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 5000/200
- Waterproof Rating: Waterproof
- Transducer Type: Transom Mount
- Touchscreen: Yes
- Speed/Temp: Temp Only
- Screen Type: Color
- Screen Size: 9'
- Resolution (VxH): 800 x 480
- Internal/External Antenna: Internal
- Included Transducer: CPT-100
- Cartography Brand: C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 13"H x 13"W x 18"L WT: 14 lbs
- UPC: 723193794340
Raymarine Active GPS Sensor f/Micronet System
$475.99
- Active GPS Antenna for use with the mn100 Micronet system.
- Easily adds Position, Course and Speed Over the Ground to your mn100 Micronet system.
- Wires directly to the T122 Wirless NMEA Interface
- Can be mounted inside or outside the boat
- 16 parallel channels
- Weighs only 108 grams without cable
- Accurate to 3.3m RMS*(DOP<3)
- Mounting: 22mm(D)x 15mm(H)Bolt
- Comes with standard (1"x14) pole mount adapter suitable for use with deck, mast and stantions
- Small form factor
- Simple installation
Quick Guide (pdf)
Raymarine ACU-100 Actuator Control Unit
$399.99
Autopilot Control Unit (ACU)
The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.
Drive Current Output
Maximum continuous 7 Amps at supply voltage
Drive Clutch Output
No clutch connection
Connections
- Rudder reference sensor
- Power
- Drive motor
- Ground
Nominal supply voltage
12 V
Operating voltage range
10.8V to 15.6V dc
Power Consumption (standby) - Main Power Supply
300 mA (12V)
Power Consumption (standby) - SeaTalkng Power Supply
No power supply to SeaTalkng
SeaTalkng LEN (Load Equivalency Number)
1
SeaTalkng Power Out
No power supply to SeaTalkng
Data Connections
SeaTalkng
Installation Environment
- Operating Temperature: -20°C to +55°C (-4°F to +131°F)
- Storage Temperature: -30°C to +70°C (-22°F to +158°F)
- Relative Humidity: MAX 93%
Waterproof rating
- Connector Panel: IPX2
- Drive Electronics: IPX6
Dimensions (W x H x D)
180mm x 140mm x 52mm (7.1 in x 5.5 in x 2.0 in)
Weight
0.6 kg (1.32lbs)
Conformance
- Europe: 2004/108/EC
- Australia and New Zealand: C-Tick, Compliance Level 2
Specifications:
- Box Dimensions: 4"H x 8"W x 12"L WT: 2 lbs
- UPC: 723193768907
Raymarine AIS100 Splitter
$299.00
Raymarine AIS100 Splitter
Second generation AIS antenna splitter for use with Class B AIS transceivers and Class A & B AIS receivers.
The AIS100 Splitter is designed to receive AIS signals and VHF transmissions simultaneously from one antenna.
Features
- Shares a single VHF antenna with Class B AIS transceiver (or Class A & B AIS receivers) and VHF radio telephone
- Near zero loss (~1-1.5 dB) - saves installing two separate antennas
- Priority given to VHF transmissions
LED power and status indicator
- Simple installation
- Compatible with any Class B AIS
- FM split output
In the Box
- AIS 100 AIS Splitter unit
- AIS RF interface cable
- VHF interface cable
- Power and FM output cable
- Quick Install guide
- User and Installation manual
- Fixing screws
Raymarine B60-12, 12 Degree Tilted Element Transducer f/DSM250 / DSM30 / DSM300 / DSM300G / CP300
$299.99
B60 Tilted Element 12°
12° titled version is designed for 8° - 15° deadrise angles
For use with Raymarine DSM250/DSM300/DSM300G/DSM30/CP300
The bronze B60-12° provide a vertical beam without a fairing. Inside the housing, the ceramic element is tilted to provide built-in deadrise compensation. The resulting vertical beam provides excellent echo returns for more accurate depth readings. The nearly flush housing minimizes drag with only 5 mm (3/16") extending outside of the hull.
Features:
- Depth/Temp
- 50/200 kHz
- 600w RMS
- Mid-performance
- Bronze
Specifications:
- Frequency: 50/200
- Mounting Style: Thru-Hull
- Speed Included: No
- Temperature: Yes
- Box Dimensions: 4"H x 8"W x 11"L WT: 5 lbs
- UPC: 723193660867
Owner's Manual (pdf)
Brochure (pdf)
Raymarine c127 Multifunction Display w/Sonar - Lighthouse Navigation Charts - NOAA Vector
$2,399.99
c127 Multifunction Display w/Sonar - Lighthouse Navigation Charts - NOAA Vector
The c-Series 12.1" c127 multifunction display (MFD) is designed to deliver no-compromise performance, incredible networking capability, and a superior user experience. Ideal for sail and power boats of all types. The c127 has a bright, sunlight viewable LCD screen and LED backlighting for maximum power savings.
The c127 is available with a convenient built-in HD Digital Sounder, capable of imaging fish and bottom structure at depths to 3,000 feet. The c127 MFD also includes a standard built-in high sensitivity GPS receiver. The c127 has dual chart reader slots for Navionics charts on microSD cards.
The c127 is a networking powerhouse with built-in Wi-Fi and Bluetooth Wireless Networking. Use the c127's Wi-Fi to stream its video display to your Apple iPhone or iPad. Synchronize waypoints and routes wirelessly to the Navionics Lakes and Marine app. Control your c127 display right from the helm with the optional RCU-3 Bluetooth Remote Control (sold separately.) The c127 can also control your smart phone or MP3 player's music playback using Bluetooth control right from the MFD.
The c127 also offer robust wired networking including SeaTalkhs, SeaTalkng, NMEA2000, NMEA 0183 and one composite video input. Network up to 6 displays together and match them with your choice of Raymarine HD Color radar scanners, sounder modules, thermal imaging cameras, SIRIUS weather receivers, AIS transceivers, marine cameras and more.
The Raymarine c127 includes a rubberized protective sun cover, flush mounting kit, power/data/video cable, installation guide and a multi-language handbook on CD-ROM.
Key Features:
- 12.1" sunlight viewable LCD displays with LED backlighting
- Built-in high-sensitivity GPS receiver
- Built-in HD Digital Sonar
- Wi-Fi video streaming and waypoint synchronization with iPhone and iPad mobile devices
- Bluetooth connectivity for optional RCU-3 remote control and multimedia control
- LightHouse user interface is extremely intuitive and places commonly used features and functions where they are easily accessed
- Dual core main processor and dedicated graphics co-processor for amazing speed and performance
- Composite video input for marine camera, thermal imager or entertainment source
- Expandable networking up to 6 displays using SeaTalkhs networking
- Mix and match any combination of c-Series or e-Series displays
- Works with Raymarine digital radar scanners, digital sounder modules, thermal night vision systems, SIRIUS weather receivers, AIS receivers, instruments, autopilots and more
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics
- Cartography Type: Hotmaps/Silver/Gold/Platinum+
- Internal/External Antenna: Internal
- Resolution (VxH): 1280 x 800
- Screen Size: 12'
- Screen Type: Color
- Touchscreen: No
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 7"H x 11"W x 17"L WT: 12 lbs
- UPC: 723193788479
Quick Guide (pdf)
Raymarine c12X/e12X Wide Adapter Kit
$149.99
C12x/E12x Wide Adapter Kit
Upgrade or Refit to New c or e-Series
If you are looking to refit your boat or upgrade your current Raymarine displays to the new e or c Series displays, we can help make life easier for you!
Upgrading is simple - using optional easy-fit bezels
- Adapter kit for C120W or E120W Wide only
- Remove your old Raymarine display from the dash
- Screw the new mounting plate (supplied pre-drilled) to the old fixing holes.
- Remove the outer bezel from your new e or c Series display.
- Fit the NEW display into the mounting plate and screw down.
- Clip the new easy-fit bezel on to the NEW display.
Raymarine c95 Multifunction Display - Lighthouse Navigation Charts - NOAA Vector
$1,699.99
c95 Multifunction Display - Lighthouse Navigation Charts - NOAA Vector
The c-Series c95 9" multifunction display (MFD) is designed to deliver no-compromise performance, incredible networking capability, and a superior user experience. Ideal for sail and power boats of all types. The c95 has a bright, sunlight viewable LCD screen and LED backlighting for maximum power savings.
The c95 MFD includes a standard built-in high sensitivity GPS receiver and also has dual chart reader slots for Navionics charts on microSD cards.
The c95 is a networking powerhouse with built-in Wi-Fi and Bluetooth Wireless Networking. Use the c95's Wi-Fi to stream its video display to your Apple iPhone or iPad. Synchronize waypoints and routes wirelessly to the Navionics Lakes and Marine app. Control your c95 display right from the helm with the optional RCU-3 Bluetooth Remote Control (sold separately.) The c95 can also control your smart phone or MP3 player's music playback using Bluetooth control right from the MFD.
The c95 also offers robust wired networking including SeaTalkhs, SeaTalkng, NMEA2000, NMEA 0183 and one composite video input. Network up to 6 displays together and match them with your choice of Raymarine HD Color radar scanners, thermal imaging cameras, SIRIUS weather receivers, AIS transceivers, marine cameras and more.
The Raymarine c95 includes a rubberized protective sun cover, flush mounting kit, power/data/video cable, installation guide and a multi-language handbook on CD-ROM.
Key Features:
- 9.0" sunlight viewable LCD displays with LED backlighting
- Built-in high-sensitivity GPS receiver
- Wi-Fi video streaming and waypoint synchronization with iPhone and iPad mobile devices
- Bluetooth connectivity for optional RCU-3 remote control and multimedia control
- LightHouse user interface is extremely intuitive and places commonly used features and functions where they are easily accessed
D - Dual core main processor and dedicated graphics co-processor for amazing speed and performance
- Composite video input for marine camera, thermal imager or 1entertainment source
- Expandable networking up to 6 displays using SeaTalkhs networking
- Mix and match any combination of c-Series or e-Series displays
- Works with Raymarine digital radar scanners, digital sounder modules, =thermal night vision systems, SIRIUS weather receivers, AIS receivers, instruments, autopilots and more
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics
- Cartography Type: Hotmaps/Silver/Gold/Platinum+
- Internal/External Antenna: Internal
- Resolution (VxH): 800 x 480
- Screen Size: 9'
- Screen Type: Color
- Touchscreen: No
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 7"H x 10"W x 14"L WT: 8.5 lbs
- UPC: 723193788424
Quick Guide (pdf)
Owner's Manual (pdf)
Raymarine CAM210 Day & Night IP Marine Bullet Camera
$699.99
CAM210 Day & Night IP Marine Bullet Camera
Ruggedised, High Definition, Day and Night network bullet video camera suitable for all above deck applications. Integrated sun-cover for maximum visibility and small frame size for easy installation anywhere on the boat.
- Plug and play integration with Raymarine MFD's running Lighthouse II
- Power over Ethernet (PoE) or direct 12V DC power supply
- High bright IR LEDs for operation in total darkness
- Digital Defog processing improves the captured image in poor weather conditions (such as smog, fog or smoke)
- Intelligent IR technology for clear video images at night in all conditions
Specifications:
- CPU: 32-bit ARM9 RISC CPU up to 432MHz
- Flash / SDRAM: 128MB / 128MB
- Image Sensor: 2.0 Megapixel 1/2.8" SONY progressive scan CMOS(Exmor)
- Total Pixels: 1952(H) x 1116(V) 2.18 Megapixel
- Effective Pixels: 1944(H) x 1104(V) 2.15 Megapixel
- S/N Ratio: More than 50dB
- Minimum Illumination: 0Lux (IR On)
- IR Distance: 20M
- Day & Night: ICR
- Lens: 6.0mm Megapixel Board Lens
- Field of View:
Diagonal = 63.6° +/- 3°
Horizontal = 53.3° +/- 3°
Vertical = 33.1° +/- 3°
- Video Compression: H.264 High Profile@4.0, MJPEG Image quality: 3 Steps
- Resolution: Up to 1920 x 1080 (Full HD)
- Frame Rate: H.264 Up to 30fps with 1920x1080 | MJPEG Up to 30fps with VGA resolution
- Video Streaming:
Support multi stream with H.264, MJPEG
Adjustable frame rate
CVBR/CBR in H.264
- Pan / Tilt / Zoom: Digital Pan, Tilt and Zoom
- Image Setting:
Day & Night
Auto White Balance
Auto Exposure
Privacy Mask
Effects - Colour, Sharpness, Mirror / V-Flip
- Security: Password protection, User access log, HTTPS encryption
- Supported Protocol: HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP
- Intelligent Video: Motion detection up to 1920x1080 with 4x3 blocks
- Power Source: DC12V/1.5A, PoE(Power over Ethernet): 802.3af
- Power Consumption: Max. 3.3W, Max. 5.3W with IR
- Net Weight: 900g
- LED's: Power, Network Connection
- Dimensions: 83.8mm(W) x 155mm(H) x 178.1mm(D) including Bracket
- General Operation Temperature: 0°~40° Celsius(32F~104F)
- Storage Temperature: -10°~50° Celsius(14F~122F)
Specifications:
- Box Dimensions: 4"H x 5"W x 10"L WT: 2.3 lbs
- UPC: 723193813263
Raymarine CP100 & CP200 System Pack w/CPT-100 & CPT-200 TM Transducers
$1,099.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWCP100 & CP200 System Pack with CPT-100 & CPT-200 TM Transducers
CP100 CHIRP DownVision™ Sonar Module with CPT-100
Raymarine's CP100 CHIRP DownVision™ Sonar Module brings powerful sonar imaging capability to Raymarine's full line of networkable multifunction displays.
Two sonars in one, the CP100 features Raymarine's CHIRP fish targeting as well as the photo-like CHIRP DownVision™ sonar. The CP100 interfaces to the RayNet (Ethernet) network enabling the CP100 to be accessed from any Raymarine network display.
Unlike conventional imaging sonars that transmit on a single frequency with each pulse, the CP100's DownVision™ sonar uses CHIRP technology to transmit across a wide spectrum of sonar frequencies with each pulse - the result is much higher-resolution, life-like sonar images.
CP100's fish targeting channel features amazing resolution enabling it to easily separate individual baitfish in a school, and distinguish the bait from predator species. Best of all, the CHIRP fish targeting can be viewed simultaneously with CHIRP DownVision™ for the ultimate view of what is underneath the water.
The ultra-compact CP100 CHIRP DownVision™ Sonar Module is compatible with all Raymarine a-Series, c-Series, e-Series and gS-Series multifunction displays. The CP100 is available bundled with the CPT-100 transom mount transducer. The CP100 Sonar module only (no transducer included) can be paired with optional plastic or bronze thru hull transducers.
Features:
- Photo-like imagery of bottom structure using CHIRP DownVision™
- CHIRP powered dual channel sonar; view high resolution DownVision™ structure imagery and target fish with CHIRP sonar simultaneously
- Perfectly matched transom mount and through hull CHIRP transducers available
- Fast response temperature sensor built into the transducer
- Maximum depth 600 feet for both channels
- Simple RayNet Ethernet connection to Raymarine a, c, e and gS Series MFDs
- CPT-100 transom mount transducer included
- Optional RayNet network cable required to complete installation:
- 2 meter RayNet Cable Part #A62361
- 5 meter RayNet Cable Part #A80005
CP200 CHIRP SideVision™ Sonar Module with CPT-200 Transom Mount Transducer
Expand your underwater horizon with the CP200 CHIRP SideVision™ sonar
The CP200 CHIRP SideVision™ Sonar expands your underwater horizon with crystal-clear, bank-to-bank displays of fish, bait and underwater structure. Engineered with the same CHIRP sonar technology as Raymarine's award winning DownVisionT the CP200 uses advanced CHIRP signal processing technology to let you see further, see more clearly, and detect more fish than traditional side scanning sonars.
Experience Visonality™
CP200 delivers side scan sonar imagery so close to reality we call it
Visionality™. See amazing photo-like imagery of underwater terrain and
man-made objects. Experience Visonality™ up to 600ft on each side.
Superior Range Performance
Raymarine CHIRP signal processing delivers high resolution and excellent
long range performance. Identify objects and see fish even further, out to
600-feet on each side!
CHIRP SideVision™ Technology
Dual independent transducer arrays. Best-in-class side scan performance using two high-performance transducer arrays with dedicated CHIRP sonar channels. High-angle setting for shallow water applications or low-angle setting for deep water applications.
See Further
Independently adjustable transducer arrays enable anglers to preset their SideVision™ transducer angle for either shallow or deep water applications. Left and Right sonar images up to 600'/183m either side of the boat.
Easy to Network
Connect the CP200 with Raymarine LightHouse II powered multifunction displays, including aSeries, cSeries, eSeries and gS Series systems.
CHIRP SideVision™ and DownVision™ Together
Combine the CP200 with CHIRP DownVision™ for the ultimate in sonar intelligence, giving you a full 180 degree view of your underwater surroundings. Add CHIRP DownVision™ to your network with a CP100 sonar or an aSeries multifunction display (DownVision™ models only).
Features:
- Network compatible CHIRP SideVision™ sonar for aSeries, cSeries, eSeries and gS Series MFDs
- Multi-sonar compatible: view CHIRP SideVision™ alongside other sources, simultaneously
- Image fish, bait and bottom structure at distances up to 600 feet horizontally per side
- CHIRP signal processing delivers crystal-clear images with amazing detail
- Works seamlessly alongside Raymarine Digital, CHIRP and CHIRP DownVision™ sonar
- Adjustable CPT-200 transducer optimizes performance for shallow or deep water scanning
CPT-200 CHIRP SideVision™ Transducer
Features:
- Transom mount CHIRP SideVision™ sonar array for the CP200
- Independently adjustable port and starboard arrays for shallow, mid or deep-water scanning
- Rugged, stainless carrier with kick-up strike protection
Specifications:
- Box Dimensions: 12"H x 12"W x 16"L WT: 14.8 lbs
- UPC: 723193788608
Raymarine CPT-100 DVS Transom Mount CHIRP Transducer
$89.99
CPT-100 DVS Transom Mount CHIRP Transducer
- Installation: Transom Mount
- Material: Urethane
- Max Depth (Ft): DV=600 | FF=900
- Frequency (KHz): CHIRP DownVision | CHIRP DownVision / Fishfinder
- Beam Width (L/H)25°/60°
- Records: Depth / Temperature
- Approved Hull Material: Fibreglass / Wood / Metal
- Cable Length (Ft/M):33'/10M
- Deadrise: 0-90° Transom
Specifications:
- Beam Width: 25°/60°
- Cable Length (Feet): 33'
- Mounting Style: Transom
- Box Dimensions: 3"H x 7"W x 10"L WT: 1.6 lbs
- UPC: 723193799246
Raymarine CPT-110 Plastic Thru-Hull Transducer w/CHIRP & DownVision™ f/CP100 Sonar Module
$269.99
CPT-110
Plastic Thru-Hull Transducer for CP100 Sonar Module
Contains two elements, one for the conical beam CHIRP sonar (center frequency 200kHz) the other for the DownVision CHIRP sonar (center frequency 350kHZ)
Contains a temperture sensor
10M Cable
Specifications:
- Cable Length (Feet): 10M
- Temperature: Yes
- Box Dimensions: 4"H x 11"W x 12"L WT: 3.4 lbs
- UPC: 723193784655
Raymarine CPT-200 Transom Mount CHIRP SideVision™ Transducer
$149.99
CPT-200 Transom Mount CHIRP SideVision™ Transducer
Features:
- Transom mount CHIRP SideVision™ sonar array for the CP200
- Independently adjustable port and starboard arrays for shallow, mid or deep-water scanning
- Rugged, stainless carrier with kick-up strike protection
- Adjustable beam angle conforms to a variety of preferences
- Integrated kick-up positioning guide ensures consistent returns to desired installation angle
Specifications:
- Mounting Style: Transom
- Box Dimensions: 4"H x 8"W x 13"L WT: 3.85 lbs
- UPC: 723193787434
Raymarine CPT-60 Transom Mount Dual Element CHIRP Transducer f/Dragonfly
$89.99
CPT-60 Transom Mount Dual Element CHIRP Transducer
The Perfect Match
For maximum performance, Dragonfly is paired with Raymarine's exclusive CPT-60 dual element CHIRP transducer. Engineered to be a perfect acoustic match to Dragonfly's CHIRP sonar, the CPT-60 is equipped with a 1.4° ultra wide fan-shaped beam for a wide view of DownVision images and industry-leading resolution.
The CPT-60 second element provides a conical shaped beam for imaging fish targets, ensuring you will never miss any of the action below your boat. The CPT-60's hydrodynamic design provides excellent high-speed performance, and an optional trolling motor mount offers added mounting flexibility.
Specifications:
- Beam Width: 1.4°
- Cable Length (Feet): 6M
- Mounting Style: Transom
- Temperature: Yes
- Box Dimensions: 5"H x 6"W x 9"L WT: 1.7 lbs
- UPC: 723193767634
Raymarine Dragonfly 5 PRO Gold Combo w/T/M Transducer & Navionics NA Gold Lakes, Rivers & Coastal Chart
$399.99
Dragonfly 5 PRO Gold Combo with T/M Transducer & Navionics NA Gold Lakes, Rivers & Coastal Chart
Raymarine Dragonfly 5 PRO US features a 5" CHIRP Sonar/GPS Combo with DownVision plus conventional sonar and has Wi-Fi built-in. Dragonfly 5 PRO includes Navionics North American Gold lakes, rivers and coastal maps.
Dragonfly 5 PRO combines GPS navigation with Raymarine's advanced dual-channel CHIRP sonar. Dragonfly 5 PRO will change your underwater view
and maximize your time fishing with Raymarine's wide-spectrum CHIRP technology. Easily identify fish and underwater objects with photo-like
sonar images from the DownVision channel and target fish with the conventional CHIRP sonar channel. A built-in 50-channel GPS delivers
precision guidance and built-in Wi-Fi lets you stream live sonar right to
your smartphone.
Superior Fishing Electronics Made Incredibly Simple
Change your underwater view and catch more fish with the Dragonfly 5PRO wide-spectrum CHIRP DownVisionT technology. Easily identify fish and underwater objects with photo-like sonar images. Dragonfly's all-weather, high-definition color LCD display looks sharp from every angle. Step up to a smarter species of sonar with Dragonfly.
The Dragonfly Difference
A leap into the future of sonar, Dragonfly sonars employ true wide spectrum CHIRP technology. With wide spectrum CHIRP more sonar signals are transmitted into the water, allowing Dragonfly to interpret more detail, target more fish, and image structure with unmatched clarity.
Features:
- 5" All-weather, high definition LED backlit display
- Optically bonded display for sharp color, wide viewing angles and no
internal fogging
- Dual-channel Sonar - Wide-spectrum CHIRP DownVision sonar for
photo-like images and a second CHIRP conventional sonar channel for
targeting fish
- Wide-spectrum CHIRP technology delivers high-speed tracking and better
deep water resolution
- Stream live sonar data to your smartphone with Raymarine's Wi-Fish
mobile app
- With the Wi-Fish you can rewind, save and share the day's catch
with friends on your favorite social networks
- Simple to use - Power on and become a Dragonfly expert in minutes
- Ball and socket tilt swivel mount lets you mount Dragonfly easily on any
surface
- Removable mounting ball is compatible with aftermarket ball and socket
mounting systems for more mounting options
- MicroSD memory card reader for saving sonar screen shots
- Includes Navionics North American Gold lakes, rivers and coastal maps
- Compatible with optional Navionics and Raymarine LightHouse format
charts
- Includes transom mount CHIRP transducer with temperature
sensor
Specifications:
- Weather Capable: No
- Waterproof Rating: Waterproof
- Transducer Type: Transom Mount
- Touchscreen: No
- Speed/Temp: Temp only
- Screen Type: Color
- Screen Size: 5'
- Internal/External Antenna: Internal
- Cartography Brand: Navionics
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 4"H x 8"W x 10"L WT: 3.3 lbs
- UPC: 723193793312
Owner's Manual (pdf)
Raymarine Dragonfly 5DVS w/T/M Transducer Dual Channel CHIRP DownVision™ & Regular Sonar
$299.00
Dragonfly 5DVS with T/M Trasducer Dual Channel CHIRP DownVision&trade & Regular Sonar
Superior Fishing Electronics Made Incredibly Simple
Change your underwater view and catch more fish with the Dragonfly 5DVS wide-spectrum CHIRP DownVisionT technology. Easily identify fish and underwater objects with photo-like sonar images. Dragonfly's all-weather, high-definition color LCD display looks sharp from every angle. Step up to a smarter species of sonar with Dragonfly.
The Dragonfly Difference
A leap into the future of sonar, Dragonfly sonars employ true wide spectrum CHIRP technology. With wide spectrum CHIRP more sonar signals are transmitted into the water, allowing Dragonfly to interpret more detail, target more fish, and image structure with unmatched clarity.
CHIRP DownVision™ - Simply The Best Imaging Sonar
CHIRP DownVision™ will change your underwater view with incredibly clear, photo-like sonar images. Dragonfly's CHIRP DownVision™ surpasses ordinary imaging sonars with superior deep water performance to 600ft (180m) and reliable high speed bottom tracking.
A Better View
Each Dragonfly is engineered with optical bonding LCD display technology. Once only available on high end marine displays, Dragonfly's all weather optically bonded displays deliver brighter colors, sharper contrast, and are guaranteed to never fog up.
Features
- 5" All-weather, high-definition LED backlit display
- Optically bonded display for sharp color, wide viewing angles, and no
internal fogging
- Dual-channel sonar - Wide-spectrum CHIRP DownVision™ sonar for
photo-like images and a second CHIRP conventional sonar channel for
targeting fish
- Wide-spectrum CHIRP technology delivers high-speed tracking and better
deep water resolution
- Simple to use - Power on and become a Dragonfly expert in minutes
- Ball and socket tilt swivel mount lets you mount Dragonfly easily on any
surface
- Removable mounting ball is compatible with aftermarket ball and socket
mounting systems for more mounting options
- MicroSD memory card reader for saving sonar screen shots
- Includes transom mount CHIRP transducer with temperature
sensor
Specifications:
- Waterproof Rating: Waterproof
- Screen Size: 5'
- Box Dimensions: 4"H x 8"W x 10"L WT: 3.1 lbs
- UPC: 723193795811
Raymarine eS127 12.1" MFD Display w/Navionics+ North American Coast + 18k Lakes Charts
$3,549.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWeS127 12.1" MFD Display w/Navionics+ North American Coast + 18k Lakes Charts
Display
- Sleek glass bridge design with three mounting options. Bracket, surface or fully recessed flush mounting
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the multifunction rotary control and keypad
Navigation
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Support for Navionics Sonar Charts and Community edits
- Sync charts, waypoint and routes between your mobile device and MFD with Navionics Boating App
- Navionics Auto Routing using Navionics + or Navionics Platinum charts
- Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Optional GA-150 external antenna connection (eS9 & eS12 only)
Sonar
- Internal ClearPulse Digital Sonar Available on eS77, eS97, eS127 models
- High performance CHIRP SideVision compatible with optional CP200
- Advanced CP370 1kW Digital sonar option for blue water fishing
- Offshore ready using optional CP470 and CP570 CHIRP sonar modules
- Sonar Command Center - view up to 4 independent sonar channels simultaneously
Video
- Monitor onboard video with support for up to 10 video of IP cameras and one analog camera
- View up to 4 cameras simultaneously
- Record and take snap shots of digital video streams
LightHouse II Software
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Raymarine's advanced HD Color signal processing with 256 color target discrimination
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Dual range mode and dual radar scanner (HD radar only)
- High speed 48rpm scanning (HD radar only)
Thermal Night Vision
- Stay safe with superior FLIR thermal night vision technology
- Easy-to-use. As simple as watching and controlling your TV
- Avoid obstacles, such as rocks, floating logs, and other debris
- Quickly identify overboard people and pets
- Slew-to-cue improves situational awareness and safety. Thermal camera automatically keeps "cued" targets in view at all times
Evolution Autopilot
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Follow waypoints and routes with unmatched precision using Evolution's aerospace derived 9-axis sensor technology
- Add a p70 or p70R pilot control head for remote control and advanced features
Engine Integration
- Complete monitoring of engines, generators, batteries and more
- NMEA 2000 compatible
- ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda and more
Digital Switching
- Control lighting, climate, navigation components, wipers, entertainment, security and much more
- State-of-the-art digital power distribution
Weather
- Stay ahead of the front with graphical weather overlays and weather reports from SIRIUSXM (USA only)
Networking
- Network compatible with any LightHouse II powered multifunction display
- NMEA2000/SeaTalkng Port for NMEA2000 and SeaTalkng connections
- NMEA0183 Input/Output
- HDMI video output (eS9 and eS12 only)
- Wi-Fi for mobile app integration
- Bluetooth for remote and MP3 control
- Fusion Stereo control
Remote Control Options
- RayControl Mobile App for iOS and Androids
- RMK-9 Wired Remote Keypad
- RCU-3 Bluetooth Wireless Remote
Specifications:
Cartography:Lighthouse, Navionics, C-MAP Essentials & C-MAP 4D MAX+
Tides & Currents:Requires Navionics or C-MAP
GPS Specs:Built-in GNSS Receiver: GPS/GLONASS/Beidou* - 10Hz 72 Channel. RS130 external GPS sensor option
Waypoints/Routes/Tracks:3,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 15 tracks - 10,000 max trk pts
Display Size:12.1" Optically Bonded LCD
Display Resolution:1280 x 800 WVGA
Display Type:Multitouch
Brightness:1,250 nits
Viewing Angle:Top / Bottom: 80 deg / 80 deg - Left / Right: 80 deg / 80 deg
Dimensions:14.1" x 8.8" x 2.6" (358mm x 223mm x 66mm)
Weight:TBD
Mounting:Flush / Bracket (R70389) / Rear (Rear Mt Accessory - A80343)
Waterproof Rating:IPX6/IPX7
Operating Temp:-13°F to 131°F (-25°C to +55°C)
Storage Temp:-22°F to 158°F (-30°C to +70°C)
Ethernet:2 x 10/100 Mbits/ Network (RayNet)
NMEA 0183: 2 Rx/1Tx NMEA0183 (On Power Cable)
NMEA 2000:1 x NMEA2000/SeaTalkng port
SeaTalk:Requires E22158 SeaTalk(1) to SeaTalkng convertor kit
Wi-FI:WiFi - 802.11 b/g
BlueTooth:Bluetooth 2.1 + EDR power class 1.5 (supports AVRCP 1.0)
Radar Capable: Yes
Thermal Night Vision Capable: Yes
Sonar Options - Built-In:Built-in 600W Digital Sonar
Transducers/Max Depth:50/200kHz 3,000'
External Sonar Module Capable:Yes Digital, CHIRP, and CHIRP SideVision Options
Memory Slot:Two MicroSD slots - up to 32GB each
Audio Integration:Fusion - Ethernet & N2K / Bluetooth / SiriusXM Audio
Video/Camera:1 x HDMI Video Out (5 meter accessory cable: A80219) 1 x Composite female BNC Input (On Power Cable) Up to 10 IP Cameras
Remote Control:RMK-9 & RCU-3
Weather:SiriusXM (Coastal) USA Only
AIS Capable:Yes
Autopilot Control:Yes - Evolution Autopilot Integration
Digital Switching:Yes - Empirbus compatible
Voltage:12V / 24V DC (10.8 V DC to 31.2V DC)
Power Consumption (Full Brightness):29.6W
Power Consumption (Powersave Mode):10W
Specifications:
- Frequency: 50/200kHz
- Resolution (VxH): 1280 x 800 WVGA
- Screen Size: 12.1'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 3,000/150
- Weather Capable: Yes
- Box Dimensions: 8"H x 11"W x 16"L WT: 14.3 lbs
- UPC: 723193798539
Raymarine eS128 12.1" Combo Wi-Fi w/CHIRP/Downvison™ Navionics+ North American Coast + 18k Lake Charts
$3,549.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWeS128 12.1" Combo Wi-Fi w/CHIRP/Downvison™ Navionics+ NorthAmerican Coast + 18k Lake Charts
High Performance Multifunction Displays
Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Features:
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications:
- Screen Size: 12.1"
- Display size: 14.1" wide x 8.8" high
- Resolution: 1280 x 800 WVGA
- Built in CHIRP/DownVision™ Sonar
- Brightness: 1250 mits
- Voltage: 12V/24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x2)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes Navionics+ NorthAmerican Coast + 18k Lake Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 3,000/150
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: Color
- Screen Size: 12.1'
- Resolution (VxH): 1280 x 800
- Internal/External Antenna: Internal
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 8"H x 11"W x 16"L WT: 14 lbs
- UPC: 723193798546
Raymarine eS78 7" MFD Combo w/Wi-Fi, CHIRP/DownVision™ Sonar & US LNC Vector Charts
$1,199.99
eS78 7" MFD Chartplotter/Fishfinder Display with CHIRP/DownVision™ Sonar & US LNC Charts
High Performance Multifunction Displays
Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Features:
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications:
- Screen Size: 7"
- Display size: 9.6" wide x 5.7" high
- Resolution: 800 x 480
- Built in CHIRP/DownVision™ Sonar
- Brightness: 1250 mits
- Voltage: 12V/24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x1)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes US LNC Vector Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 3000/150
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: cOLOR
- Screen Size: 7'
- Resolution (VxH): 800 x 480 WVGA
- Internal/External Antenna: Internal
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 10"H x 9"W x 12"L WT: 6.8 lbs
- UPC: 723193798218
Quick Guide (pdf)
Brochure (pdf)
Raymarine eS78 7" MFD Combo w/Wi-Fi, CHIRP/Downvision™ Sonar w/US C-MAP Essentials Charts
$1,249.99
eS78 7" MFD Chartplotter/Fishfinder Display with CHIRP/Downvision™ Sonar with US C-MAP Essentials Charts
High Performance Multifunction Displays
We are pleased to announce the launch of the Raymarine eS Series line of HybridTouch multifunction displays. Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Key Features
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications
- Screen Size: 7"
- Display size: 9.6" wide x 5.7" high
- Resolution: 800 x 480
- Built in Chirp/Downvision Sonar
- Brightness: 1250 mits
- Voltage: 12V / 24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x1)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes US C-Map Essentials Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 3000/150
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: cOLOR
- Screen Size: 7'
- Resolution (VxH): 800 x 480 WVGA
- Internal/External Antenna: Internal
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 9"H x 10"W x 12"L WT: 6.8 lbs
- UPC: 723193796146
Quick Guide (pdf)
Brochure (pdf)
Raymarine eS98 9" Combo Wi-Fi CHIRP/Downvision™ Sonar & US LNC Chart
$2,299.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWeS98 9" MFD Chartplotter/Fishfinder Display with CHIRP/DownVision™ Sonar & US LNC Charts
High Performance Multifunction Displays
Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Features:
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications:
- Screen Size: 9"
- Display size: 11.8" wide x 6.8" high
- Resolution: 800 x 480
- Built in CHIRP/DownVision™ Sonar
- Brightness: 1250 mits
- Voltage: 12V/24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x2)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes US LNC Vector Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 3000/150
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: Color
- Screen Size: 9'
- Resolution (VxH): 800 x 480 WVGA
- Internal/External Antenna: Internal
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 8"H x 9"W x 14"L WT: 10.3 lbs
- UPC: 723193794746
Brochure (pdf)
Raymarine eS98 9" Combo Wi-Fi w/CHIRP/Downvision™ Sonar w/US C-MAP Essentials Charts
$2,349.99
$200 or More in Cash Back w/Qualifying Purchases UNTIL 09/03/2017 VIEWeS98 9" MFD Chartplotter/Fishfinder Display with CHIRP/DownVision™ Sonar & US C-MAP Essentials Chart
High Performance Multifunction Displays
Powered by Raymarine's advanced LightHouse II user interface, the eS Series includes three high-performance navigation displays that offer unprecedented control and ease-of-use in a sleek, ergonomic design.
The eS Series features a choice of 7", 9" and 12" displays, each with an attractive, glass bridge-style design that blends seamlessly with today's modern helm stations, allowing for both low profile console and a completely recessed flush mounting option.
Features:
- Super bright displays (1250 nits) with optical bonding technology for sharper colors and contrast
- HybridTouch - Responsive touch screen control with pinch to zoom or simple keypad interaction using the new multifunction rotary control and keypad
- Sleek glass bridge design with three mounting options. Bracket, surface, or (optional)fully recessed flush mounting
- Powered by Raymarine's powerful LightHouse II operating system
- Easy-to-use, easy-to customize, and easy-to-expand. Network eS Series with any LightHouse II powered display
- Engineered for the future with regular LightHouse updates and enhancements
- Access your eS Series from anywhere on board. Built in Wi-Fi allows you to stream to Raymarine mobile apps and sync with the Navionics Boating app
- Freedom to choose the very best charts from C-MAP by Jeppesen, Navionics, and Raymarine's expanding LightHouse chart catalog
- Navionics Auto Routing using Navionics + or Navionics Platinum charts and support for Jeppesen Easy Routing using C-MAP 4D MAX+ charts
- Fast 10 Hz GPS/GLONASS internal receiver for rapid chart position updates and faster satellite acquisition
- Available wide spectrum CHIRP DownVision on eS78, eS98 and eS128 models and ClearPulse Digital sonar on eS77, eS97 and eS127 models
- High performance side scanning sonar using the optional CP200 CHIRP SideVision sonar
- Sonar Command Center - view up to 4 independent sonar channels simultaneously, including the CP370 Digital and CP470 and CP570 CHIRP Sonars
- Monitor and record onboard video with support for up to 10 video over IP cameras like the Raymarine CAM200IP
- Network with Raymarine Digital, HD Color and Super HD Color radar systems
- Best-in-class automatic Bird Mode for finding flocks of birds above schools of fish (HD radar only)
- Navigate safer at night with optional thermal night vision cameras and slew-to-cue target tracking
- Engage and control Raymarine Evolution autopilots directly from the eS Series chartplotter display
- Engine Integratin- Complete Monitoring of engines, generators, batteries and more. NMEA2000 complatible. ECI-100 Universal Connectivity for Yanmar, Yamaha, Honda, and more.
- Digital Switching- Vessel Automation and control system. Control lighting, climate, navigation components, wipers, entertainment, security and much more. State-of-the-art digital power distribution. Super realiable and cost-effective. Simple, custom graphical interface
Specifications:
- Screen Size: 9"
- Display size: 11.8" wide x 6.8" high
- Resolution: 800 x 480
- Built in CHIRP/DownVision™ Sonar
- Brightness: 1250 mits
- Voltage: 12V/24V DC (10.8V DC to 31.2V DC)
- Built-in GPS Sensor: 10 Hz GPS/GLONASS
- Ethernet: RayNet Ports-(x2)
- NMEA2000: SeaTalkng-(xl)
- NMEA0183 input/output: Yes
- Memory Slot: MicroSD (x2) up to 32GB each
- Includes US C-Map Essentials Charts
- Wi-Fi for mobile app integration: Yes
- Bluetooth: Yes
- Waterproofing Standard: IPX6 and 7
- Warranty: 2 Years upgradable to 3 Years
Specifications:
- Weather Capable: Yes
- Waypoints/Routes: 3000/150
- Waterproof Rating: Waterproof
- Transducer Type: Not Included
- Touchscreen: Yes
- Screen Type: Color
- Screen Size: 9'
- Resolution (VxH): 800 x 480 WVGA
- Internal/External Antenna: Internal
- Cartography Type: Hotmaps/Navionics+/Gold/Platinum+/4D Max
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Box Dimensions: 8"H x 9"W x 14"L WT: 10.25 lbs
- UPC: 723193796153
Brochure (pdf)
Raymarine EV-100 Power Evolution Autopilot
$1,499.99
EV-100 Power Evolution Autopilot
Features:
- A complete autopilot-in-a-box
- Type 0.5 Hydraulic Pump included
- Evolution Ai for superior performance
- No calibration required
- Ideal for small, hydraulically steered powerboats
- Built-in trolling patterns
- For 12V DC power systems
- Includes p70R Autopilot Controller
Includes:
- EV-1 Sensor Core
- p70R Autopilot Control Head
- ACU-100 Actuator Control Unit
- Type 0.5 Hydraulic Pump 12V
- Evolution Cabling Kit
- EV Unit O-Ring Pack (set of 2)
- Wall Mounting Bracket
The EV Sensor Core
At the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.
Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.
The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkng and NMEA2000 networks.
Features:
- Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change
- Flexible installation options
- Mount above or below deck
- Simple SeaTalkng connectivity to the control head and ACU
- Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions
- Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays
P70R Autopilot Control Head
The p70R has a convenient rotary control knob and support for multiple autopilot modes including Auto, standby, trolling patterns, and track mode from your GPS or chartplotter.
Features:
- LightHouse user interface is simple and quick to use
- Wide 160° viewing angles
- Start up wizard helps you configure the pilot quickly and easily
- Anti-reflective coating for improved visibility in bright sunlight
- Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness
- Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer
- Simple system and group dimming/illumination
- Support for multiple data sources
- SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required)
ACU-100 Autopilot Control Unit (ACU)
The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.
Support Drive Units
Type 0.5 Hydraulic Pump included-3.1" to 6.7" cu in ram
Evolution Cabling Kit
- 1 x SeaTalkng Power Cable (0.4m)
- 1 x SeaTalkng Backbone Cable (5m)
- 1 x SeaTalkng Spur Cable (0.4m)
- 1 x SeaTalkng 5-way Connector Block
- 2 x SeaTalkng T-piece Connector
- 2 x SeaTalkng Terminator
Specifications:
- Drive Type: Hydraulic
- Box Dimensions: 8"H x 17"W x 20"L WT: 14.5 lbs
- UPC: 723193774281
Quick Guide (pdf)
Brochure (pdf)
