Simrad
- All products listed below are in stock and ready to ship.
- Orders are shipped same day when placed before 4PM Est. and are shipped from our east coast warehouse
- Free Shipping on Orders over $200 USD
- For AIS purchase please fill out the AIS form and email filled out form to info@marineelectricsystems.net with order number
Simrad NSS7 evo3 7" Chartplotter/Fishfinder/Radar Bundle
$2,999.00
NSS7 evo3 7" Chartplotter/Fishfinder/Radar Bundle
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder
technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS7 evo3 features a 7-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 7-inch widescreen SolarMAX HD display.
- Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
- Add StructureScan® 3D imaging, advanced Broadband Sounder capabilities and more via Simrad modules
- Expand your view with Halo Pulse Compression radar, Broadband 3G/4G, and other Simrad radar solutions
- Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
- NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
- Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
- Enjoy easier trip planning with TripIntel technology and support for
- Navionics Autorouting/C-MAP Easy Routing (automatic routing unavailable in North America)
- Built-in GoFree Wi-Fi enables online features and smartphone monitoring/tablet control
- Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
- Includes Insight chart
- Dimensions without bracket and knobs: 9.41"w x 5.90H
- Dimensions with brack and knbos: 10.35"w x 6.31"h
4G Broadband Radar with 20M Cable
For optimal target separation, Broadband 4G Radar is the world's first dome radar to use Beam Sharpening, which significantly improves azimuth resolution - the effective horizontal beam width of the radar signal. The result is a resolution that is equivalent to a 3.5-foot, open-array radar. When combined with a Simrad NSE, NSS evo2 NSO evo2 NSS evo3 or B&G Zeus2 multifunction display, the system's user-defined, target-separation control allows users to adjust the level of separation to meet specific navigational needs. The Simrad and B&G Broadband 4G Radars' exclusive dual-range functionality - available with Simrad NSE, NSO and B&G Zeus displays - makes them the only recreational radars capable of displaying distances from 200 feet to 36 nautical miles - all from a single dome.
The ultimate navigational safety tool, Broadband 4G Radar allows boaters to see a buoy 200 feet away on the multifunction display, while simultaneously monitoring coastal projections up to 36 nautical miles. In addition, Simrad and B&G Broadband 4G Radar models can track up to 10 MARPA targets per range - each with independent control, for a total of 20 tracked targets in split-screen mode.
All Broadband 4G Radars provide an unequalled number of working ranges, 18, for premier performance and navigational awareness. Providing intuitive and easy-to-use operation, each model also features smart, pre-defined Offshore and Harbor modes on all ranges without requiring special tuning knowledge.
Broadband 4G Radar not only raises the bar in radome performance by providing far superior resolution at long-range distances, it also delivers the same exceptional close-range capability signature to Broadband Radar. The system marks objects within 6.5 feet (2 meters) of the boat, providing target definition and separation in close quarters where traditional pulse radar is blind. Maintaining high-sensitivity and clarity in all weather conditions, the radar provides easy-to-view detail of targets even in high-sea states. Additional Broadband 4G Radar safety and convenience features include: revolution speeds up to 36 rpm for Lowrance HDS and Simrad NSS, and 48 rpm for Simrad NSE, NSO and B&G Zeus - providing near-instant
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics/C-Map
- Cartography Type: Navionics+/Platinum+/Max - N+
- Frequency: 40-250kHz 455-800kHz
- Internal/External Antenna: Internal
- Resolution (VxH): 600 x 1024
- Screen Size: 7'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 6000/500
- Weather Capable: Yes
- Box Dimensions: 25"H x 24"W x 24"L WT: 42.5 lbs
- UPC: 9420024162019
Simrad NSS9 evo3 Chartplotter/Fishfinder/Radar Bundle
$3,949.00
NSS9 evo3 9" Chartplotter/Fishfinder MFD
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder
technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS9 evo3 features a 9-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 9-inch widescreen SolarMAX HD display.
- Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
- Add StructureScan® 3D imaging, advanced Broadband Sounder capabilities and more via Simrad modules
- Expand your view with Halo Pulse Compression radar, Broadband 3G/4G, and other Simrad radar solutions
- Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
- NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
- Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
- Built-in GoFree Wi-Fi enables online features and smartphone monitoring/tablet control
- Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
- Includes Insight chart
- Dimensions without bracket and knobs: 11.30"w x 6.55"H
- Dimensions with brack and knbos: 12.24"w x 7.07"h
4G Broadband Radar with 20M Cable
For optimal target separation, Broadband 4G Radar is the world's first dome radar to use Beam Sharpening, which significantly improves azimuth resolution - the effective horizontal beam width of the radar signal. The result is a resolution that is equivalent to a 3.5-foot, open-array radar. When combined with a Simrad NSE, NSS evo2 NSO evo2 NSS evo3 or B&G Zeus2 multifunction display, the system's user-defined, target-separation control allows users to adjust the level of separation to meet specific navigational needs. The Simrad and B&G Broadband 4G Radars' exclusive dual-range functionality - available with Simrad NSE, NSO and B&G Zeus displays - makes them the only recreational radars capable of displaying distances from 200 feet to 36 nautical miles - all from a single dome.
The ultimate navigational safety tool, Broadband 4G Radar allows boaters to see a buoy 200 feet away on the multifunction display, while simultaneously monitoring coastal projections up to 36 nautical miles. In addition, Simrad and B&G Broadband 4G Radar models can track up to 10 MARPA targets per range - each with independent control, for a total of 20 tracked targets in split-screen mode.
All Broadband 4G Radars provide an unequalled number of working ranges, 18, for premier performance and navigational awareness. Providing intuitive and easy-to-use operation, each model also features smart, pre-defined Offshore and Harbor modes on all ranges without requiring special tuning knowledge.
Broadband 4G Radar not only raises the bar in radome performance by providing far superior resolution at long-range distances, it also delivers the same exceptional close-range capability signature to Broadband Radar. The system marks objects within 6.5 feet (2 meters) of the boat, providing target definition and separation in close quarters where traditional pulse radar is blind. Maintaining high-sensitivity and clarity in all weather conditions, the radar provides easy-to-view detail of targets even in high-sea states. Additional Broadband 4G Radar safety and convenience features include: revolution speeds up to 36 rpm for Lowrance HDS and Simrad NSS, and 48 rpm for Simrad NSE, NSO and B&G Zeus - providing near-instant updates at ranges less than 2 nautical miles; directional sidelobe-clutter suppression to reduce clutter and echoes Specifications
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics/C-Map
- Cartography Type: Navionics+/Platinum+/Max - N+
- Frequency: 40-250kHz 455-800kHz
- Internal/External Antenna: Internal
- Resolution (VxH): 600 x 1280
- Screen Size: 9'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 6000/500
- Weather Capable: Yes
- Box Dimensions: 24"H x 25"W x 25"L WT: 44 lbs
- UPC: 9420024162026
Simrad NSS7 evo3 Chartplotter/Fishfinder with Insight Charts
$1,299.00
NSS7 evo3 7" Chartplotter/Fishfinder MFD
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder
technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS7 evo3 features a 7-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 7-inch widescreen SolarMAX HD display.
- Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
- Add StructureScan® 3D imaging, advanced Broadband Sounder capabilities and more via Simrad modules
- Expand your view with Halo Pulse Compression radar, Broadband 3G/4G, and other Simrad radar solutions
- Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
- NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
- Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
- Enjoy easier trip planning with TripIntel technology and support for
- Navionics Autorouting/C-MAP Easy Routing (automatic routing unavailable in North America)
- Built-in GoFree Wi-Fi enables online features and smartphone monitoring/tablet control
- Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
- Includes Insight chart
- Dimensions without bracket and knobs: 9.41"w x 5.90H
- Dimensions with brack and knbos: 10.35"w x 6.31"h
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics/C-Map
- Cartography Type: Navionics+/Platinum+/Max - N+
- Frequency: 40-250kHz 455-800kHz
- Internal/External Antenna: Internal
- Resolution (VxH): 600 x 1024
- Screen Size: 7'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 6000/500
- Weather Capable: Yes
- Box Dimensions: 9"H x 9"W x 13"L WT: 6.8 lbs
- UPC: 9420024154038
Simrad NSS9 evo3 Chartplotter/Fishfinder with Insight Charts
$2,299.00
NSS9 evo3 9" Chartplotter/Fishfinder MFD
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder
technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS9 evo3 features a 9-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 9-inch widescreen SolarMAX HD display.
- Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
- Add StructureScan® 3D imaging, advanced Broadband Sounder capabilities and more via Simrad modules
- Expand your view with Halo Pulse Compression radar, Broadband 3G/4G, and other Simrad radar solutions
- Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
- NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
- Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
- Built-in GoFree Wi-Fi enables online features and smartphone monitoring/tablet control
- Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
- Includes Insight chart
- Dimensions without bracket and knobs: 11.30"w x 6.55"H
- Dimensions with brack and knbos: 12.24"w x 7.07"h
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics/C-Map
- Cartography Type: Navionics+/Platinum+/Max - N+
- Frequency: 40-250kHz 455-800kHz
- Internal/External Antenna: Internal
- Resolution (VxH): 600 x 1280
- Screen Size: 9'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 6000/500
- Weather Capable: Yes
- Box Dimensions: 10"H x 12"W x 16"L WT: 8.4 lbs
- UPC: 9420024154045
Simrad NSS7 evo2 Radar Bundle
$2,199.00
NSS7 evo2 Multifunction Display with 3G Radar Bundle
The NSS evo2 combines form, fit and function in an easy-to-use multifunction device. The integrated NSS evo2 MFD features a sleek display with TouchSensible multi-touch interaction. TouchSensible, provides precision interaction in any sea condition with its logical keypad input and rotary, push-to-enter knob. With its widescreen 16:9 display, integrated StructureScan and Broadband sonar, and expandability the NSS evo2 is well suited for center consoles, sportfishing and power cruising boats.
Key Features:
- TouchSensible interface with multi-touch control and rotary dial with keypad
- Embedded, hi-gain 10Hz GPS/GLONASS antenna
- 16:9 display with pre-set and customizable navigation panels
- Flush-mount installation and classic black and brushed silver trim panels
- Embedded CHIRP enabled Broadband sounder and StructureScan Sonar
- Complete vessel integration
- Best in Class Performance:
- Fast Processor
- Bright Screen
- Easy to Use
- Intelligent Engineering:
- Low Profile (~8mm) front mount option
- Glass-Bridge look for any vessel
- GPS works in flush mount installations* (*on MOST non-metal boats)
- Full autopilot integration capability
- Simrad GoFree WiFi integration capability
- Networking capability
- Fast Processor
HEROiC Software
The NSS evo2's HEROiC Software has been engineered for ease of use and to maximize the benefits of widescreen multi-touch display technology. HEROiC has an updated look and feel for Simrad while maintaining the familiar features for the seasoned Simrad user:
- Easy to access via single press of the Home key
- Quick access to key page tiles in center of the display via a single press
- Quick access to configurable favorites on the Right
- System settings and more complex setup menu controls on the Left
- Easy to access via single press of the power key or dragging down the status bar from the top of the display
- Quick access to settings related to the page in view
- Quick access to brightness controls, Night mode, TouchScreen lock
- Adjust panel split ratios and turn instrument bar on/off
- Radar transmit/standby controls
- Audio/Autopilot controls
- Customer / boatbuilder can choose from the pre-loaded desktop images or load their own.
- Mixed-mode user control to provide a powerful multi touch user interface that can also be operated by a keypad when the sea conditions get challenging
- Pinch to zoom Chart, Echo, Radar
- Drag the status bar down from the top of the display to access system controls
- OP40 Remote Controllable
- Brings the familiarity of Tablet/Smartphone controls to marine electronics
Simrad Broadband 3G Radar
Faster, better, longer...
Join the Broadband Radar revolution for superior short-range target detection and unrivalled target separation.
- Crystal Clear Images
- Zero Radiation Hazard
- InstantOn
- Low Power Consumption
- Mount Anywhere
- Quick Installation
- Unrivalled Short-Range Performance
- 10 MARPA Targets
Now with 30% more range.
Broadband 3G Radar allows you to see more targets farther away from your boat. Now you get the same impressive short-range capabilities of the original Broadband Radar with the addition of exposing targets previously unseen before.
Unparalleled Short Range Target Discrimination - Where it Matters Most
Simrad Yachting's Broadband Radar provides amazing target resolution, even at an unprecedented 1/32 nm range. Docks, channel markers, moored vessels and other critical targets are displayed with clarity and separation, for added confi dence in close quarters. Broadband Radar technology also eliminates the "main bang" of a pulse radar - the obscured "dead zone" immediately around the vessel - which interferes with close target detection.
Lowest RF Transmission for Safe, Flexible Installation
Because Simrad Broadband Radar transmits at 1/10,000 the power of typical pulse radars (emitting 5 times less energy than an average cell phone), the radome is safe to mount in locations never before possible. In addition, the lowest DC power draw of any X-band marine radar makes this system ideally suited for sailboats and other vessels with limited power.
Navigation in an Instant
No more waiting 2-3 minutes for a magnetron to warm up - 100% solid-state design provides InstantOn capability. When darkness falls or the fog rolls in, you will always be ready. Ideal for sailboats wishing to save power, or boats at anchor not wishing to run the radar continuously.
SPECIFICATIONS
RADAR
Antenna Beam Width Horizontal 5.2°+/-10% (-3dB width) °
Antenna Beam Width Vertical 25°+/-20% (-3dB width) °
Antenna Receiver Noise Figure 6 dB
Antenna Rotation Speed 24/36 rpm +/- 10% RPMs
Radar Warm Up Time 0 min
Radar Wind Resistance 51 m/sec (Max:100 Knots)
COMMUNICATIONS
Transmitter Frequency X-band - 9.3 to 9.4Ghz
Transmitter Power Output 165mW nominal
Data I/O Protocol High Speed Ethernet
TECHNICAL / ENVIRONMENTAL
Mounting Bolts: 4x30xM8 - 304 stainless steel
Waterproof Standard IPX6
Height 280 mm \ 11 in
Diameter 488 mm \ 19.2 in
Weight 7.4 kg \ 16.31 lbs
Humidity +35°C (95xF) 95% RH
POWER
Power Supply 9V to 31.2Vdc (12/24 Volt systems) Reverse polarity protection vDC
Power Consumption 18W (Typ.) @ 13.8Vdc
Power Consumption Standby 2W (Typ.) @ 13.8Vdc - only 150ma
GENERAL
Compliance CE, FCC (ID: RAY3G4G), IC: 4697A-3G4G
OTHER
Interconnection Cable 20M (66ft) standard with RJ45 thin custom (Max 30m)
Interface Heading SimNet or NMEA 0183 with cable kit into display
Operating Temperature -25° to +55°C (-13° to +130°F)
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics/C-Map
- Cartography Type: Platinum/Gold/Hotmaps
- Internal/External Antenna: Internal
- Resolution (VxH): 800x480
- Screen Size: 7'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 28"H x 26"W x 28"L WT: 43.8 lbs
- UPC: 9420024157442
Simrad 6kW 4' Open Array Radar w/20M Cable & Radar Processor
$3,999.00 $4,585.00
6kW 4' Open Array Radar With 20M Cable & Radar Processor
The Simrad HD Digital radar ensures exceptional detection of small or distant targets,using advanced Digital Signal Processing (DSP). They present targets more clearly and reject clutter using 10-bit digital radar video sampling and Sensitivity Time Control (STC). Screen-clutter in any weather is virtually eliminated allowing a clear, accurate and easy to interpret image.
Chart Overlay
Adding a heading input from an autopilot system or dedicated sensor will allow the radar image to be overlaid on the chart. Targets can be interpreted instantly with respect to chart information such as navigation aides and coastlines.
Color Palettes
Different color palettes are provided to suit users tastes as well as improve viewing in different lighting conditions. In addition, Simrad's HD Digital radars automatically adjust color gradients on distant targets for better target definition. This is especially useful when looking at storm centers.
Guard-Zone Alarms
Easy to use guard zone areas can be defined by the user. This allows the mariner to maintain a radar watch in specific zones. Any radar return or target in that area will trigger an alert on the radar system.
Specifications:
- Array Size (Inches): 4ft
- Power - Output (Kilowatts): 6kw
- Range - Max (Miles): 72nm
- Box Dimensions: 19"H x 17"W x 26"L WT: 98 lbs
Owner's Manual (pdf)
Simrad HALO™-6 Pulse Compression Radar w/6' Antenna, RI-12 Interface Module & 20M Cable
$5,500.00 $5,600.00
HALO™-6 Pulse Compression Radar with 6' Antenna, RI-12 Interface Module & 20M Cable
Combining the best characteristics of traditional pulse and FMCW broadband radar systems, Simrad's Halo Radar uses Pulse Compression technology to provide an unprecedented mix of long and short detection range, high target definition, and minimal clutter. Solid State technology means minimal warm-up time and maximum ocean-going reliability, while compliance with upcoming Low Emission standards makes Halo Radar safe to run in anchorages and marinas.
Key Features:
- True 72nm range with 6' open array antenna
- Beam Sharpening with Target Separation Control
- Dual Range operation with NSS/NSO multifunction displays
- Advanced signal processing with Harbour, Offshore, Weather, Bird, and Custom modes. Other modes available soon.
- High-speed 48RPM operation
- InstantOn, ready in 16-25 seconds from power-on, instant from standby
- MARPA target tracking, up to 10 targets (20 with dual range)
- Low electromagnetic emissions and radiation
- Low power consumption with 12/24V operation
- Ethernet connectivity
- Unique blue LED accent lighting in pedestal with brightness control
Solid-State with Pulse Compression Technology
Simrad Halo Radar is the world's first high performance, solid-state radar with pulse compression technology designed specifically for recreational mariners. Unlike traditional pulse radar, Halo Radar isn't reliant on a high-powered magnetron (vacuum tube) to transmit. Instead, Halo Radar uses solid-state electronics and low-power 25W pulsed, frequency-swept transmission bursts to deliver pulse radar-like range and resolution, without the associated warm-up time, power consumption, or electromagnetic emissions.
72nm Range
Halo Radar delivers a maximum range comparable to traditional 6kW pulse radar, at up to 72nm with the HALO-6 Radar's 6' open array antenna. It offers unprecedented 10M (30') minimum range, peering into that pulse-radar blind spot where once only FMCW (3G/4G) Broadband Radar could operate.
Beam Sharpening
Whether you're looking at a flock of birds or a string of channel markers, separating one radar target from another is key. Beam Sharpening with Target Separation Control provides unmatched target resolution, granting the Halo Pulse Compression Radar's 6' open array antenna the same effective target resolution as a 6' array without beam sharpening.
Dual Range Operation
With Dual Range, Halo Radar functions like two arrays in one - monitor two distance ranges simultaneously with independent displays, controls, and totally independent MARPA target tracking. Take full advantage of Halo Radar's combination of short-, mid-, and long-range performance to keep an eye on faraway weather cells, while monitoring channel markers and high speed watercraft up close. Dual Range operation is available with Simrad NSS and NSO multifunction display systems.
Target Detection
The HALO-6 Radar offers excellent target detection for its compact 6' open array.
ARPA Target Tracking
Automatically track up to 10 user-selected radar targets, displaying CPA (closest point of approach) and TCPA (time to closest point of approach). Up to 20 different targets can be tracked in Dual Range mode, with 10 targets per screen. MARPA functionality requires a heading sensor and GPS.
Advanced Signal Processing
Halo Radar employs advanced signal processing for digital azimuth and range sidelobe reduction, enhancing discrimination of small targets such as channel markers from larger adjacent targets such as ships and bridges. In addition, Directional Sea Clutter Rejection dynamically changes gain in the sweep to allow smaller targets to be seen in the leeward. Sector Blanking eliminates unwanted reflections, for less clutter on screen.
8 Usage Modes with Automatic Harbour/Offshore Selection
Harbour, Offshore, Weather, and Bird modes tune Halo Radar's advanced signal processing to help ensure the targets you're interested in can be seen vividly - even in the toughest environmental conditions. Automatic selection of Harbour and Offshore modes configures your Halo Radar to suit your surroundings, while a 'Custom' mode enables easy manual tuning to suit any purpose or condition
High Speed Mode Halo Pulse Compression Radar provides rapid position updates, with high speed operation up to 48RPM (mode and range dependent). Simrad quality construction and Halo Radar's brushless motor with advanced helical geartrain design ensure exceptionally quiet operation, especially at 48RPM.
InstantOn
Collision hazards won't wait for your radar to start up - why should you? Halo Radar's solid-state technology is ready instantly from standby, and in just 16-25 seconds from power-on to fully-operational. Avoid the 2-3 minute warm-up time associated with traditional pulse radar, and trust Halo Radar =to produce an immediate, accurate radar image when you need it.
High Reliability
Halo Radar is built to last, with its solid-state transceiver meaning no magnetron to replace, and no manual tuning required as the magnetron heats up or ages. Similarly, a solid-state brushless motor driver means no motor brushes to wear out and replace. Be confident that Halo Radar will operate at high speed in winds up to 70 knots, year after year.
Low Electromagnetic Emissions
Unlike traditional pulse radar, Halo Radar's low-power pulsed transmissions meet upcoming Low Emission standards. This makes Halo Radar safe to run in anchorages and marinas, providing enhanced radar coverage at the very start and end of each journey.
Low Power Consumption
Halo Radar uses 40W average with no wind, and no more than 200W at maximum wind velocity. Experience even greater power savings in standby with just 7W power usage, versus 10/15W for pulse radar. With its low power consumption and support for 12/24 volt DC systems, Halo Radar is ideal for small to mid-sized powerboats.
Ethernet Connectivity
Simrad Halo Pulse Compression Radar connects to any Simrad NSS or NSO multifunction display system via Ethernet, with a bulkhead-mounted interface box below deck. Antenna installation is simple and elegant, with the same thin cable and small-diameter connectors as our 3G/4G Broadband radars.
Uncompromising Aesthetics
Bringing the range and reliability of Halo Pulse Compression Radar to your boat doesn't mean compromising on aesthetics. Halo Radar's sleek open-array antenna sits atop a uniquely curved pedestal, a departure from traditional boxy and utilitarian radar designs. Display your Halo Radar on the water with soft-glow, dual-beam Blue LED accent lighting, integrated into the pedestal and customizable with 4-level brightness control.
*Halo Pulse Compression Radar's blue 4 level static accent pedestal lighting may not be approved for use in your boating location. Please check your local boating regulations before turning the blue accent lights ON.
Specifications:
- Range - Max (Miles): 78nm
- Power - Output (Kilowatts): 6kW
- Array Size (Inches): 6'
- Box Dimensions: 20"H x 18"W x 18"L WT: 78.55 lbs
- UPC: 9420024128824
Simrad NAC-3 VRF Core Pack - NAC-3, Precision-9 & N2k Starter Kit
$1,950.00
NAC-3 VRF Core Pack - NAC-3, Precision-9 & N2k Starter Kit
Comprising of the high-current NAC-3 Autopilot computer, Precision-9 compass & N2k Starter Kit.
The NAC-3 Autopilot Computer is the brains behind your autopilot system. NAC-3 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-3 was designed for boats 10M(33') or greater in length and is rated to operate high-current hydraulic drives, mechanical drive units, and solenoid valves with a current rating of 30 Amps continuous (50 Amps peak).
Precision-9 Compass
The Precision-9 Compass supplies heading and rate-of-turn information to Simrad, B&G and Lowrance autopilot, radar and navigation systems. Based on reliable solid-state sensor technology, this compact compass offers easy installation aboard any vessel.
N2k Backbone Starter Kit
NMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminators
Features:
- Heading, Rate Of Turn (ROT), roll, and pitch output over NMEA 2000®
- Heading and ROT calculated using sensor data from 9 axes of rotation and motion
- Accurate and reliable solid-state sensor technology
- Heading accuracy of ±2° after calibration
- Easily adjustable mounting bracket allows bulkhead or up-mast installation
- IPX7 waterproof. Best in class.
- Simple installation with a single NMEA 2000® connection
Specifications:
- Temperature, operation: 0 to +55°C
- Temperature, storage: -32 to +70°C
- Protection: IPx7
- Weight in Kg: 0.7kg, 1.6lbs
- Dimmension Max size, mm (length x width x height): 211 x 196 x 65.5mm, 8.31" x 7.72" x 2.58"
- Mounting: Bulkhead
- Construction: Plastic
- Color: Black
- Cable inlet: Grommet (Spare Incl)
- Local power supply: 12/24 V DC +10-30%
- NMEA 2000 Load Equivalent number (50mA): 1
- Reversible motor control of rudder: Max continious load 30A, peak 50A for 1s
- On/off solenoid control of rudder: 12/24V DC, common, load range 10mA to 10A, off current <1mA
- Engage output for bypass/clutch: 12/24V DC, min 10mA, max 3A
- Rudder angle, frequency input: 15V, 1.4 to 5kHz, resol. 20Hz/° OR NMEA2000
- NFU port/stbd input and mode indicator output: External open/close contact, common ret, contact current max 30mA
- Mode input: External open/close or pulse contact for SYSTEM SELECT, common ret, close to activate, contact current max 30mA
- External alarm output for buzzer/relay: Max 100mA, voltage level as local supply
- IEC 61162-1 input (NMEA0183 In): 1 ch
- IEC 61162-1 output (NMEA0183 Out): 1 ch
- IEC 61162-1 speed: 4.8 & 38.4 kbaud
- NMEA2000: Certified (pending)
Specifications:
- Box Dimensions: 10"H x 10"W x 16"L WT: 7 lbs
- UPC: 9420024155660
Simrad NAC-2 VRF Core Pack - NAC-2, Precision-9 & N2k Starter Kit
$1,249.00
NAC-2 VRF Core Pack - NAC-2, Precision-9 & N2k Starter Kit
Comprising of the high-current NAC-3 autopilot computer, Precision-9 compass & N2k Starter Kit.
The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10M (33') in length and is suitable for low-current hydraulic drives, mechanical drives, or solenoid valves with a current rating of 8 Amps continuous (12 Amps peak).
Precision-9 Compass
The Precision-9 Compass supplies heading and rate-of-turn information to Simrad, B&G and Lowrance autopilot, radar and navigation systems. Based on reliable solid-state sensor technology, this compact compass offers easy installation aboard any vessel.
N2k Backbone Starter KitNMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminators
Features:
- Heading, Rate Of Turn (ROT), roll, and pitch output over NMEA 2000®
- Heading and ROT calculated using sensor data from 9 axes of rotation and motion
- Accurate and reliable solid-state sensor technology
- Heading accuracy of ±2° after calibration
- Easily adjustable mounting bracket allows bulkhead or up-mast installation
- IPX7 waterproof. Best in class.
- Simple installation with a single NMEA 2000® connection
Specifications:- Operating temperature: -25°C to +55°C (13°F to 131°F)
- Protection: Splashproof, IPx5
- Weight: 0.6 kg (1.3 lbs)
- Overall Dimensions: Width: 7.1" \ 180mm / Height: 2.2" \ 57mm
- Power supply: 9-31.2 V DC
- Load: 140 mA + drive unit load
- Performance: Drive: 8 A cont., 16A for 1s
- Network: 1xMicroC (NMEA2000)
- Feedback: Variable voltage/resistive 0-5V
- Drive output: To PUMP-1 or HELM-1
- Power supply: 9-31.2 V DC
- Solenoid: 12/24V DC, common, load range 10mA to 10A, off current <1mA
- Clutch: 12/24V DC, min 10mA, max 3A
Precision 9 Specifications:- Dimensions: H: 36mm (1.42"), W & D: 119mm (4.69")
- Weight: Module - 165g (5.8oz), Bracket - 130g (4.6oz)
- Supply and interface: 8-16 V via NMEA 2000
- Power consumption: 0.4 W
- NMEA 2000 Load Equivalence No. (LEN): 1
- NMEA 2000 ports (input/output): 1
- Calibration: Automatic (User Prompted)
- Repeatability: ± 1.0° (or better)
- Roll/Pitch range: ± 45°
- Heading accuracy: ± 2° after calibration
- Dynamic performance: with random excitation of ± 10° at max 1 Hz: |Heading error <2°: with heading step input of 90° at a rate of 10°/s: |Heading error 10 sec. after turn <2°
- Environmental protection: IPx7
- Compass safe distance: 0.5M(1.7')
- Temperature range operation: -25 to +65°C (-13 to +149°F)
- Temperature range Storage: -30 to +70°C (-22 to +158°F)
Specifications:
- Box Dimensions: 10"H x 10"W x 16"L WT: 7.2 lbs
- UPC: 9420024155653
- Operating temperature: -25°C to +55°C (13°F to 131°F)
Simrad AP44 Autopilot Controller
$599.00
AP44 Autopilot Controller
Rotary dial course adjuster, optically bonded 4.1" color display
The AP44 Autopilot Controller combines Simrad Continuum steering technology with a full colour display, intuitive rotary dial and button controls, and modern glass helm styling. Free your hands from the wheel, cruise in comfort, and discover new ways to search for fish; this dedicated controller offers easy access to automated turn patterns, No Drift steering, depth contour tracking, and other advanced pilot features. Connect your chartplotter to add waypoint and route navigation, and enjoy full autopilot control from compatible Simrad displays.
Features:
- Rotary-dial course adjustment with new intuitive autopilot control
- Optically bonded 4.1" color display
- Easy setup with auto tuning and calibration
- Simrad Continuum steering technology
- All new intuitive autopilot control
- Automated turn patterns
- No Drift steering
- Depth contour tracking
- Low-profile 'Glass Helm' design
- Low power consumption
- Certified NMEA 2000® connectivity
Intuative Autopilot control
The point of a dedicated autopilot controller is to enable immediate access to auto-steering functionality, placing key controls within easy reach. Designed with that purpose in mind, the AP44 includes an intuitive interface with just four buttons and a push-to-enter rotary control dial
Automated turn patterns
Your Simrad autopilot can do much more than keep you on course. The AP44 gives you easy access to a range of built-in turn patterns designed to assist with fishing, diving, or just making a quick and efficient U-turn.
Simrad Continuum steering>B
Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues today at Simrad Yachting's autopilot research hub in Norway
Easy setup with auto tuning and calibration
Autopilot installation and commissioning doesn't have to be difficult or time consuming. The AP44 offers automatic tuning to ensure optimal auto-steering performance, with a simple on-screen commissioning process including dockside configuration and sea trial.
Specifications:
- Dimensions: 118 x 115 x 28mm (4.6 x 4.5 x 1.1")
- Weight: 0.32kg (0.7lbs)
- Power Consumption: 1.8 Watts (MAX)
- Network Load: 3 LEN
- Color: Black
- Display Size: 4.1" (diagonal). 4:3 Aspect ratio
- Display Type: Transmissive TFT-LCD, bonded. White LED backlight
- Dsiplay Resolution: 320 x 240 pixels
- Illumination: White for day mode. Red, green, blue or white for night mode
- Environmental Protection, Waterproof: IPx7
- Environmental Protection, Humidity: up to 95% RH
- Compass Safe Distance: 300mm (1.0")
- Temperature Operating: -15 to +55°C (5°F to +131°F)
- Temperature Storage: -30 to +70°C (-22 to +158°F)
Specifications:
- Box Dimensions: 5"H x 6"W x 9"L WT: 1.6 lbs
- UPC: 9420024155141
Simrad B175H-W Bronze Thru-Hull 0° Tilted Element™ Transducer - Wide Beam CHIRP - 1kW
$1,424.99 $1,499.00
B175H-W Wide Beam CHIRP, 1 kW, Tilted-Element
Description
The B175H-W is a bronze, thru-hull CHIRP transducer, ideal for sportfishing and commercial vessels up to 8 m (25 ft) in size. This single-channel transducer offers High CHIRP combined with a wide beam for the best resolution and coverage in shallower depths.
Features
- 7 Pin Blue Connector
- Depth & Temperature
- 130-210 kHz High CHIRP with wide 25° beam for excellent fish targets
- Up to 310 m (1000 ft) range with High CHIRP
- 1 internal broadband ceramic
- 1 kW
- High-Performance
- Bronze
- SonarHub sounder module & Simrad NSS evo2 multifunction displays
Single Channel CHIRP
Using pulsed transmissions swept across a range of frequencies, CHIRP technology delivers superior target resolution and depth penetration to traditional single-frequency sonar. This single channel CHIRP transducer operates anywhere in the 130-210 kHz High CHIRP frequency range, with a 25° beam width. With High CHIRP, the B175H-W provides an operating depth of up to 310 m (1000 ft).
Wide Angle CHIRP
Ideal for anglers, the B175H-W's wide-angle technology delivers a constant 25° beam width across the transducer's 130-210 kHz High CHIRP frequency range. This achieves up to double the coverage beneath your boat, and provides enhanced fish detection in the upper water column, versus the narrower beam of other high-frequency CHIRP transducers.
Depth/Temperature
One sensor does it all. Able to measure both depth and temperature in a single package, the B175H-W simplifies installation and requires just one connection to your echosounder module or multifunction display.
Specifications:
- Beam Width: 0°
- Temperature: Yes
- Speed Included: No
- Pins: 7 Pin Blue
- Mounting Style: Thru-Hull
- Frequency: 130-210kHz
- Box Dimensions: 10"H x 8"W x 12"L WT: 11 lbs
- UPC: 9420024133347
Simrad B175L-20 Chirp Transducer - 20° Tilt
$1,416.99 $1,490.00
B175L-20 CHIRP Transducer - 20° Tilt
The B175L is a bronze, thru-hull CHIRP transducer, ideal for sportfishing and commercial vessels up to 8M (25') in length. This single-channel transducer offers Low CHIRP only, for great depth penetration.
Features:
- 40-60 kHz Low CHIRP with 32-21° beam width
- Up to 1200M (4000') range
- 7 internal broadband ceramics
- Thru-hull with bronze housing
- Suitable for fiberglass and wood hulls
- Ideal for sportfishing and commercial vessels up to 8M (25') in length
- Recommended for use with the BSM-3 broadband sounder module, SonarHub sounder module & Simrad NSS evo2 multifunction displays
Single Channel CHIRP
Using pulsed transmissions swept across a range of frequencies, CHIRP technology delivers target resolution and depth penetration superior to traditional single-frequency sonar. This single channel CHIRP transducer operates anywhere in the 40-60 kHz Low CHIRP frequency range, with a 32-21° beam width. The B175L provides an operating depth of up to 1200M (4000').
Depth/Temperature
One sensor does it all. Able to measure both depth and temperature in a single package, the B175L simplifies installation and requires just one connection to your echosounder module or multifunction display.
Deadrise Compensation
The B175L's 20° tilt to compensate for deadrises of 16-24°. With ceramic elements tilted inside the housing to aim the beam straight down without a fairing block, these transducers are able to deliver more accurate depth readings and best cover the area directly beneath your boat.
Mounting
With bronze housing, the B175L is suitable for thru-hull mounting in fiberglass and wood hulls. Thru-hull mounting places the transducer in the water on the outside of your boat's hull; a hole must be drilled for installation. This typically offers the best depth measurement and fishfinding performance.
Specifications:
- Frequency: 40-60 kHz
- Box Dimensions: 8"H x 11"W x 12"L WT: 12 lbs
- UPC: 9420024123652
Simrad GO7 Suncover f/Flush Mount Kit
$24.99
GO7 Suncover for Flush Mount Kit
Make sure your GO7 continues to work like new by protecting it with the GO7 suncover. This sturdily made covers fits perfectly. It protects from overexposure to sun glare during long boat trips. The suncover is UV ray resistant.
Simrad HS35 Wireless Handset f/RS35
$157.99 $169.00
Simrad HS35 Wireless Handset
Use your Simrad RS35 VHF/AIS Radio wherever you are on your boat, with the HS35 wireless handset. Easy to use and with full VHF functionality, this innovative handset gives you total freedom of movement on board your boat.
Wireless Control
Make calls, scroll through channels, view AIS data and even initiate distress functions with this easy to use handset.
Intercom
Communicate with the base station and other remote stations to relay vital information to crew members.
Inductive Charging
Simply charge using the induction plate on the back of the Handset for 8 hours of battery life
Up to 100m Range
The long operational working range covers even the largest of vessels.
Keypad Lock
Avoid unintentional operation, the handset also includes a handy belt clip and headphone jack for freeing your hands.
Fully Waterproof
Certified to IPX7 standard.
Whats in the Box
HS Wireless Handset
Charging Cradle
Belt clip
User Guide
Mounting Hardware
Simrad IS40 Speed/Depth Package w/Nylon Thru-Hull Triducer
$941.99 $999.00
IS40 Color Instrument Display with Nylon Thru hull Triducer
Part# 000-10955-001
The IS40 is an easy to use, flexible, full color, digital instrument display
offering best in class performance. Featuring multiple data pages, the IS40
enables you to clearly read the information you want, when and where you
want. When coupled with the intuitive OP10 autopilot controller and the
necessary computers and drives, it can operate as a standalone autopilot or
it can easily be integrated as part of a much larger electronics system.
Large Multi Data Display
A tough, sunlight viewable screen, with clear digits and a display that's
almost 40% larger than its rivals. Read wind, speed, depth, boat speed,
heading, autopilot status, engine data and much more.
Full Color
Enjoy an extremely bright display with the latest LCD technology, day or
night.
Easy Installation
Micro-C connectors provide for quick and easy connection - ideal for
retrofit or new build. Compatible with industry standards.
Simrad Yachting Construction
Elegantly designed yet brutally strong.
Highly Visible Bonded LCD
Greater contrast for increased readability with a massive 170 degree viewing
angle. Zero condensation ensures a clearly visible screen in all seasons
providing outstanding longevity and durability.
Easy To Use
Large keys, a dedicated Page button and straightforward menus allow instant
access to the data you require
Expandable
Choose a simple network and expand it to fit your requirements with full
Simrad NSS and NSE chartplotter compatibility
Package includes:
IS40 Display- 000-10931-001
Nylon Thru hull - 22098552
Micro-c Backbone kit - 000-10760-001
Specifications:
- Transducer Type: Thru-Hull
- Box Dimensions: 9"H x 11"W x 13"L WT: 4.9 lbs
- UPC: 9420024121429
Simrad LFI3000 Mk2 Linear Feedback Interface Box Only
$152.00
LFI3000 Mk2 Linear Feedback Interface Box Only
Interface unit for LF3000 Linear Feedback. It converts the analog LF3000 signal to standard digital feedback signal for the autopilot steering computer.
Specifications:
- Box Dimensions: 5"H x 6"W x 7"L WT: 0.8 lbs
- UPC: 809190313453
Simrad Micro-C Female to SimNet Cable - 1M
$24.99 $25.00
Micro-C Female to SimNet Cable
Simrad's Micro-C Female to SimNet 1M Cable
Simrad NSE/NSS Video/Data Cable - 6.5'
$24.99 $39.99
NSE/NSS Video/Data cable
NSE / NSS Video/Comms Cable (8 pin conn. to bare wires for NMEA and 2 RCA female for Video in Port one and two) 2M (6.5')
Simrad RS90 Handset & Speaker Kit - Comes w/5M(16.5') Cable
$299.00 $349.00
RS90 Handset & Speaker Kit
Expansion handset kit f/RS90 Black Box VHF Radio
Comes with 5M(16.5') Cable
Specifications:
- Box Dimensions: 3"H x 10"W x 12"L WT: 2.8 lbs
- UPC: 9420024126745
Owner's Manual (pdf)
Simrad RS90 VHF Radio
$799.00 $899.00
RS90 VHF Radio
Stay connected with the Simrad RS90 VHF. Designed for sport fishermen and power boaters, the RS90 is loaded with innovative features to make communication easier on the water.
This exclusive RS90 VHF function is for safety, teamwork, convenience, and even just for fun. It's a great feature that allows you to connect your VHF DSC position polling with chartplotter to show the location of up to three boating friends on the chart display.
It's also easy to set up: You need a RS90 fixed mount VHF, the MMSI number of your buddies' VHF DSC radios and a Simrad GPS chartplotter. Your VHF will regularly poll your buddies' positions, and the chartplotter will regularly update their locations by MMSI number on your screen. Track-Your-Buddy is a truly great aid in locational awareness of your friends in a group boating excursion.
Features:
- Premium black box VHF Radio
- Continues the Simrad legacy in VHF radio
- Flexible options with wired and wireless handsets
- Enhanced features to support intra and inter vessel communication
- 6 Stations, 4 wired and 2 wireless, unmatched in the market
- Alpha numeric keypad for professional users
- Track Your Buddy when connected to a Navico MFD
- 30W PA/Horn output with Listen back features
- Dedicated horn key for immediate and action, no menu fumbling
- Scrambler option for private communications
- Future features include DSC calls to AIS targets from handset and compatible MFD plus advanced intercom facilities
- Voice record 30 second rewind and listen back
Additional Features:
- All Internationl, Canadian and U.S. Channels
- Dual channel AIS receiver
- ATIS mode for European inland waterways
- Built-in hailer - 30 Watts
- Built-in foghorn with 4 selectable patterns
- 2-pin cable of external horn key to activate horn without handset
- Handset built to meet JIS7
- Intercom facility between stations
- 10 weather channel with 1050hz alert tone detect (for U.S.)
- Selectable 25/1 Watt Transmit Power
- DSC Capability Class D
- Support private channels (able to vary by dealer at site by PC program)
- GPS Input for Automatic Time and Position Update
- NMEA 2000 Interface and NMEA 0183 connectivity
- Local/Distance function
- Dual Watch/TRI Watch Function
- 3 Channel funtions
- All Channel Priority Scan
- Backlight sync between MFD and VHF handset
- 20 User Programmable names with MMSI
- Call Log: 10 distress calls and 20 individual calls for DSC communications
Specifications:
- Channels - Available: All US, Canadian, International
- DSC Class: D
- Hailer/Intercom: Both
- Power - Output (Watts): 25/1 Watt
- Remote Mic Capable: Yes
- Scrambler Capable: Yes
- Box Dimensions: 5"H x 10"W x 16"L WT: 7.7 lbs
- UPC: 9420024126738
Simrad Mercury Verado Hose - 6' Pair
$199.99 $202.00
Mercury Verado Hose - 6' Pair
Product Details
- Product Dimensions: 14" x 13" x 5"
- Weight: 1.8lb
Specifications:
- Box Dimensions: 5"H x 13"W x 14"L WT: 1.8 lbs
- UPC: 745061687851
Simrad DST800 235khz Transducer f/IS20 Combi
$323.99 $339.00
DST800 Thru Hull Transducer for IS20 Combi Display
Simrad's DST800 active D/S/T TH plastic 235 kHz transducer with 2 m (7 ft) cable.
Specifications:
- Fairing Block Included: No
- Frequency: 235khz
- Mounting Style: Thru-Hull
- Speed Included: Yes
- Temperature: Yes
- Box Dimensions: 4"H x 6"W x 8"L WT: 1 lbs
- UPC: 042194901480
Simrad AP44 VRF Medium Capacity Pack - AP44, NAC-2, Precision 9 & RPU80
$2,499.00
AP44 VRF Medium Capacity Pack - AP44, NAC-2, Precision 9 & RPU80
The AP44 Autopilot Controller combines Simrad Continuum steering technology with a full color display, intuitive rotary dial and button controls, and modern glass helm styling. Free your hands from the wheel, cruise in comfort, and discover new ways to search for fish; this dedicated controller offers easy access to automated turn patterns, No Drift steering, depth contour tracking, and other advanced pilot features. Connect your chart plotter to add waypoint and route navigation, and enjoy full autopilot control from compatible Simrad displays.
Key Features:
- Rotary-dial course adjustment with new intuitive autopilot control
- Optically bonded 4.1-inch color display
- Easy setup with auto tuning and calibration
- Simrad Continuum steering technology
- All new intuitive autopilot control
- Automated turn patterns
- No Drift steering
- Depth contour tracking
- Low-profile 'Glass Helm' design
- Low power consumption
- Certified NMEA 2000® connectivity
Intuitive Autopilot control
The point of a dedicated autopilot controller is to enable immediate access to auto-steering functionality, placing key controls within easy reach. Designed with that purpose in mind, the AP44 includes an intuitive interface with just four buttons and a push-to-enter rotary control dial
Automated turn patterns
Your Simrad autopilot can do much more than keep you on course. The AP44 gives you easy access to a range of built-in turn patterns designed to assist with fishing, diving, or just making a quick and efficient U-turn.
Simrad Continuum Steering
Every Simrad steering innovation builds upon a legacy encompassing over sixty years of autopilot development, which continues today at Simrad Yachting's autopilot research hub in Norway.
Easy setup with auto tuning and calibration
Autopilot installation and commissioning doesn't have to be difficult or time consuming. The AP44 offers automatic tuning to ensure optimal auto-steering performance, with a simple on-screen commissioning process including dockside configuration and sea trial.
NAC-2
The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10M (33') in length and is suitable for low-current hydraulic drives, mechanical drives, or solenoid valves with a current rating of 8 Amps continuous (12 Amps peak).
Precision-9
The Precision-9 Compass supplies heading and rate-of-turn information to Simrad, B&G and Lowrance autopilot, radar and navigation systems. Based on reliable solid-state sensor technology, this compact compass offers easy installation aboard any vessel.
Unique Selling Points- Heading, Rate Of Turn (ROT), roll, and pitch output over NMEA 2000®
- Heading and ROT calculated using sensor data from 9 axes of rotation and motion
- Accurate and reliable solid-state sensor technology
- Heading accuracy of ۬° after calibration
- Easily adjustable mounting bracket allows bulkhead or up-mast installation
- IPX7 waterproof. Best in class
- Simple installation with a single NMEA 2000® connection
Specifications:
- Box Dimensions: 14"H x 11"W x 19"L WT: 15.8 lbs
- UPC: 9420024155165
- Heading, Rate Of Turn (ROT), roll, and pitch output over NMEA 2000®
Simrad IS35 Digital Display
$349.00 $399.00
IS35 Digital Display
The IS35 is used to display engine and vessel related data on the network provided by NMEA2000 compatible engines and sensors. The types of data available for display are determined by the available NMEA2000 sensors on the network. You can use the IS35 as engine display for most types of marine engines, either via a NMEA2000 gateway, or a J1939 to NMEA2000 convertor. (for example the Livorsi CAN Data Gateway). The IS35 comes with 5 pre-configured pages for the most commonly used information when operating vessels. The information on these pages is automatically displayed from an internal hierarchy of available data. The hierarchy was developed from market and customer surveys about which information the boat owners themselves consider the most important information to see on their displays
Features
- Automatic display of prioritized dynamic data types. (RPM, fuel flow, economy, speed etc
- Bright, full color 240 x 360 LED screen makes it easier to see menus and screen detail in both full sunlight and night operation
- Menu button doubles as backlight control
- Simple menu navigation using menu, arrow and enter buttons
- Easily swap between pages using arrow keys
- Page cycle with configurable times
- Surface mount, or flush/rear mount option
Pre configured data pages
- Motoring
- Engine Monitoring
- Fuel Economy
- Depth History
- Motor Steer
- Device will automatically detect available sensors on the network and display the most relevant information on the corresponding pages
User Interface The IS35 is running on the NOS (Navico Operating System) platform. Anyone that is familiar with Navico products will quickly and easily understand the user interface of the IS35. Power Control The unit automatically starts up when N2K bus is powered. The IS35 can't be powered off but can be put into standby. Refueling You can quickly set the fuel to full, or add a fuel amount directly from pressing menu on the fuel page, or by the settings menu and going to `Fuel'. Auto scroll The IS35 can be set to automatically scroll through the pages ranging from 1 to 10 seconds.
Key Selling Features
- Easy to install
- Fits standard gauge hole
- Display NMEA2000 engine information affordably
- Automatically displays information relevant to which sensors are installed
- Easily display fuel management information
- Glass dash low profile display
- Rear mount option for flush mount glass dash installs
- Automatic page scrolling with configurable adjustable delay time
- Simple user interface
- Dedicated engine display
- Display following information on non-NMEA2000 engines by installing sensors:
- Fuel flow
- Fuel used
- Fuel remaining
- Water pressure
Specifications:
- Display Resolution: 320 x 240 (H x W)
- Display Type: LED-backlit TFT-LCD
- Display: Backlighting Color [text]: Day (white) / Night (red)
- Display Size: 88.9mm / 3.5"
- Environmental Rating: IPX7
- Operating Temperature: -15°C to 55°C (5°F to 131°F)
- Product Width: 102mm (4.0")
- Product Depth: 122mm (4.8")
- Product Height: 99.7mm (3.9")
- Product Weight: 0.28kg (0.60lb)
- Power Consumption: 130mA @ 13.5V
Simrad SimNet Cable 2M
$41.99 $42.00
SimNet Cable 2M
SimNet (Simrad Intelligent Marine Network) is a unique marine electronics network system. Over the last 5 years, it has proven to be one of the most reliable and easy to use networks in the marine industry. SimNet is easy to install with thin cables and small plugs.
Simrad ST800 S/T Plastic Ducer w/DT800 f/IS20
$104.99 $109.00
ST800 S/T Plastic Ducer with DT800 for IS20
Simrad's ST800 Speed/Temp Plastic Transducer is used with the DT800 for the IS20.
Specifications:
- Temperature: Yes
- Speed Included: Yes
- Box Dimensions: 4"H x 6"W x 8"L WT: 1.3 lbs
- UPC: 421949015038
Simrad RPU300 All Regions Drive Unit - 12V
$1,374.00
RPU300 All Regions Drive Unit 12V - 32-36 Cu In Ram
For Cylinder Displacement of 23–36 cu. in. (NAC-3 / AC42 required)
The RPU300 is a reversible hydraulic steering pump for boats up to 70ft. It works in conjunction with the NAC-3 / AC42 autopilot computer as part of an autopilot system.
Features:
- Reversible Pump
- High Flow Rate
- 12V DC
- 290-960 cc
Specifications:
- Box Dimensions: 5"H x 5"W x 12"L WT: 10 lbs
- UPC: 809190358690
Simrad Yamaha Helm Gateway Autopilot Kit
$2,749.99 $3,040.00
Yamaha Helm Master Gateway Autopilot Kit
What is Yamaha Helm Master?
- Helm Master is the Electronic steering and control system for Yamaha outboards
- Outboards can be controlled independently allowing the boat to rotate on the spot or dock sideways
Key Features
- Fully integrated with your Simrad Navigation system via NSS, NSE, NSO
- Control the SG05 Autopilot directly from your MFD
- All the modes you'd expect from a Simrad Autopilot: Auto, Nav, NoDrift, FollowUp
Included:
- 000-11241-001 - YAMAHA HELM MASTER GATGEWAY FOR SG05
- 24006793 - SG05 AUTOPILOT COMPUTER VOLVO IPS/YAMAHA
- 000-10613-001 - RC42N, RATE COMPASS, MICRO-C
- 000-0119-79 - N2K-T-RD, MICRO-C, T JOINER
- 24005729 - CABLE MICRO-C MALE TO SIMNET 0.5M
Simrad GS25 GPS Antenna
$199.00 $209.00
High-Sensitivity GPS/GLONASS Antenna
w/Built-in Compass Deliver Faster, More Accurate Position-Update Rates For Smoother Chartplotting Functionality
The Simrad GS25 antenna provides best-in-class GPS/GLONASS positioning along with industry-leading, 10Hz GPS performance for smooth and accurate location updates. Equipped with an integrated electronic compass with GPS, the antenna provides accurate heading for stable chart orientation in the Heading Up mode, improved Course Over Ground at low speeds and radar overlay on your chart. All of these features are possible with affordable module options that easily connect through an NMEA 2000® network.
Compatibility
Simrad NSE, NSO & NSS Multifunction Displays
Key features of the GS25:
- NMEA 2000 antenna module offers rugged and precise position, and heading sensor
- Spot-on, around-the-world accuracy - supporting GPS and GLONASS, WAAS/EGNOS/MSAS; Galileo-capable with future software update
- Excellent time-to-first-fix, with 10Hz, multi-GNSS, high-speed updates - up to 10 times per second - for smoother and more accurate location updates
- Integrated electronic compass with GPS provides vessel heading with rate stabilization that provides heading output for accurate chart orientation in the Heading Up mode, improved Course Over Ground at low speed, and radar overlay (not intended for MARPA or Autopilot Control)
- Rugged design for all marine environments and fully waterproof
- Include spat/pole mount for easy installation and flexible boat location for optimal performance
- Independent source selection on any display
Specifications:
- Box Dimensions: 4"H x 8"W x 11"L WT: 1.55 lbs
- UPC: 9420024122747
Owner's Manual (pdf)
Simrad NSS16 evo2 Chartplotter / Multifunction Display
$4,499.00
NSS16 evo2 Chartplotter / Multifunction Display
The NSS evo2 combines form, fit and function in an easy-to-use multifunction device. The integrated NSS evo2 MFD features a sleek display with TouchSensibleTM multi-touch interaction. TouchSensible, provides precision interaction in any sea condition with its logical keypad input and rotary, push-to-enter knob. With its widescreen 16:9 display, integrated StructureScanTM and Broadband sonar, and expandability the NSS evo2 is well suited for center consoles, sportfishing and power cruising boats.
The NSS16 evo2 is engineered for performance, functionality and flexible control. Its TouchSensibleT interface provides multi-touch interaction for ease of use when cruising, as well as a keypad and a rotary push-to-enter knob for quick and effective use on those days when waves and boat movement make it hard to use a touch-screen accurately. The NSS16 evo2's 16:9 widescreen display features a tablet-style home screen with pre-set navigation panels and programmable favorites for concise display of information, and easily identifiable touchscreen function keys. The screen's background can be customized with a picture of a boat, crew, fish, destination and more.
The NSS16 evo2 incorporates technology designed for blue water anglers and cruisers and provides a wealth of expansion options for boaters to get the most from their excursions. SonarHub is integrated in the NSS16 evo2 and combines award-winning StructureScanT Sonar, Broadband Sounder and CHIRP technology to give anglers the ability to view fish and structure in both 3D imaging and high-definition sonar. The NSS16 evo2 also provides full autopilot integration for control from its TouchSensible display; and the embedded high-gain 10 Hz GPS antenna provides precise location information.
The Simrad GoFree WiFi option allows viewing and control of the NSS screen from a compatible tablet as well as viewing from a compatible phone. The system's networking capability allows the addition of extra screens, display of engine and the ability to control an iPhone music playlist via the navigation screen. NSS16 evo2 integration can be extended for complete vessel control with digital switching, night-vision camera control (FLIRT) or HDMI video output to a TV in the salon. Cartography compatibility includes Insight, C-Map MAX-N and Navionics.
Engineered for form and function, the NSS16 evo2 enhances the helm of any vessel. Its flush-mount design provides a professional, low profile look that is complemented by classic black or brushed silver trim panels - both included with every system.
Key Features
- Low Profile Glass Design
- More Screen, Less Border
- Widescreen, Multi Touch Display
- Built in High Gain 10Hz GPS/GLONASS
- Built in CHIRP/Traditional sonar
- Built in StructureScan
- 4 display sizes 7”, 9”, 12” & 16”
- High Brightness Displays
- All new HEROiC Software
- OP40 remote operable
- Chartplotter only versions available
- Networks with existing NSS, NSE, NSO series MFDs
- Networks with all Simrad Performance Modules
- 8mm Dash Profile: Family Matched with New MO Monitors
- OP40 Remote Controllable
- All new HEROiC Software has been engineered for ease of use and to maximise the benefits of widescreen multi-touch display technology.
- HEROiC has an all new look and feel for Simrad while maintaining the familiar features for the seasoned Simrad user
- HEROiC has been designed for mixed-mode user control to provide a powerful multi touch user interface that can also be operated by a keypad when the sea conditions get challenging
- HEROiC software is more customisable, allowing users to completely configure the system to their needs.
- Personalised Wallpaper
- Fully customisable favourites that can be accessed by a long press of the ‘Home’ key: HEROiC utilizes multitouch gestures for object manipulation and menu access. These types of controls are mainstream in todays Tablet/Smartphone market and very intuitive and easy to adapt to.
- Pinch to zoom Chart, Echo, Radar
- Drag the status bar down from the top of the display to access system controls
- OP40 Remote Controllable
NSS evo2 inherits all the existing software feature from NSS RTM 3.0 plus more new for evo2:
- FLIR M-Series camera control
- OP40 Remote controllable
- Dual Radar
- 48RPM Radar Support
- BEP C-Zone Integration
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics
- Cartography Type: Platinum/Gold/Hotmaps
- Included Transducer: No
- Internal/External Antenna: Internal
- Resolution (VxH): 1366 x 768
- Screen Size: 16
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 9"H x 14"W x 22"L WT: 19 lbs
- UPC: 9420024125373
Simrad GO9 XSE Chartplotter/Fishfinder w/TotalScan Transducer & 4G Radar Bundle
$2,699.00
GO9 XSE Chartplotter/Fishfinder w/TotalScan Transducer & 4G Radar Bundle
GO9 XSE Multi-function display with built in Echosounder, GPS and Wi-Fi. Super-bright, 9" multi-touch widescreen display with NMEA 2000 and radar interface. Includes 4G Radar and TotalScan Transom Mount Transducer.
Features:
- Easy to use, High brightness 9" tablet style touchscreen
- Built-in advanced echosounder capable of displaying CHIRP, Forwardscan, Sidescan and Downscan images
- Radar port for connection to a Simrad solid state radar
- Direct Audio, Autopilot, communication and engine connection and control over NMEA2000
- Built-in WiFi for mobile device mirroring and internet downloads of charting and software
- Easy to use multi touch software
- Safely and easily navigate using your favourite cartography (Insight, Navionics, CMAP)
- Determine depth, bottom type and find fish using one of the many echosounder technology options
- Quick and simple control of entertainment systems connected on NMEA2000
- Vessel circuit control when connected to a C-zone digital switching system
- View and monitor engine data while underway
- Low Profile Glass dash styling
- Super bright widescreen display
- Built in Wi-Fi connectivity
- Software update notifications and downloads when connected to the internet
- Screen mirroring when connected to a mobile device
- Built in 10 Hz GPS antenna
- Dual Micro SD card slot
- Built in echosounder (Broadband & Chirp)
- Built in DownScan and Sidescan Imaging (transducer required)
- Built in Forwardscan Imaging (transducer required)
- Radar port for direct connection to Simrad 3G/4G or Halo Radar scanners
- Operable with OP40/OP50 Remote
- Advanced NMEA2000 networking
Easy to Use Multi-Touch Display
The GO9 XSE offers true ease of use with intuitive touchscreen controls that smartphone and tablet users will find instantly familiar. Tap to create or select waypoints, pinch to zoom, or tap and drag to pan smoothly across charts. Simple home screen and menu layouts make all functions quickly accessible, with large and clearly-captioned icons that are easy to recognise and tap.
Chartplotter Navigation & Waypoint Management
The GO9 XSE is a full-featured chartplotter, with support for the widest available range of cartography options including C-MAP® MAX-N, Navionics®, Insight®, Insight Genesis®, and NV Digital® Charts. Navigate confidently to destinations near and far, with the flexibility to choose charts that best fit your needs and location. Set and record those destinations easily with simple waypoint mangement: mark waypoints with a touch, and assign meaningful names that make it easy to look up your desired destination whether youve mapped out ten places or a thousand.
Expand Your View with a Simrad Radar Solution
The Simrad GO9 XSE is a full-featured radar display with plug-and-play connectivity to Simrad Broadband 3G, Broadband 4G, and Halo Pulse Compression radar systems. Cruise confidently through crowded harbours, navigate safely in poor visibility, keep an eye on distant weather cells, and find flocks of feeding birds that hint at good fishing spots. Automatic tuning helps to provide a clear radar picture in any conditions, while radar overlay combines radar data with navigational charts for an easy-to-interpret view of your surroundings.
Fully Customisable Interface
The Simrad GO9 XSE is fully customisable to suit your vessel and your favourite on-water activities from power boating, to fishing, to water sports. Customise your home screen with shortcuts to the features you use most, and personalise it with your choice of wallpaper. Adjustable split-screen views and customisable panel layouts let you see everything you need on-screen at once, whatever your activity.
Plan Smarter with TripIntel Technology
Designed for power boaters, TripIntel technology tracks and displays the key information you need to plan safe and enjoyable days on the water. Make smart decisions with fuel range overlaid on charts, easy access to current and future tide levels, and a detailed history of your previous trips including the route you took and how your boat performed.
Built-in 10 Hz GPS receiver*
With a high-speed GPS receiver updating your position ten times every second, the Simrad GO9 XSE is ideal for use aboard fast-moving RIBs and powerboats. Watch your boat's movement tracked smoothly, accurately, and in real-time, without 'jumping' from point to point on the display.
Cruise Charting View
Designed with power boating in mind, the Simrad GO9 XSE offers a unique Cruise Charting page that brings together crucial navigation data and charts in one easily readable display. Choose the information most relevant to your crusing style and on-water activities with the ability to edit on-screen data items.
NMEA 2000® Engine Monitoring & Instrumentation
The Simrad GO9 XSE connects to any NMEA 2000®-capable equipment aboard your vessel including outboard and inboard engines; fuel level and flow meters; speed, heading, and water temperature sensors; and much more. Create your own custom digital instrument displays, bringing a wealth of information to even the most crowded dash while keeping a clean look with as few gauges as possible.
Watch Your Depth with Built-in Sonar
Knowing the true depth beneath your hull can help you enjoy your time on the water with fewer worries, and makes it easier to locate suitable anchorages in unfamiliar waters. With built-in sonar, just add a suitable sonar transducer for accurate, real-time depth tracking. A scrollable depth history view lets you track back and easily set waypoints for promising anchorages, while StructureScan Imaging combines DownScan and SideScan sonar to offer a picture-like view of the bottom beneath your vessel.
Cruise Confidently with ForwardScan Sonar
Using an optional ForwardScan transducer, this forward-looking sonar technology provides a clear two-dimensional image of the bottom in front of your vessel, allowing you to navigate shallow or poorly-charted waters with confidence. With real-time updates and a forward-looking view of up to eight times your current depth, ForwardScan lets you relax and enjoy a safer day on the water.
Find fish with CHIRP & StructureScan® HD sidescan imaging
Whether fishing is your life or just a casual hobby, any fishing trip will benefit from the extensive array of built-in sonar technology on the Simrad GO9 XSE. Add a suitable transducer, available separately or bundled with your display, and the GO9 XSE works as a powerful fishfinder with CHIRP-enabled broadband sonar for clear detection of fish throughout the water column. With an optional HDI or TotalScan transducer, the GO9 XSE also offers StructureScan HD sidescan imaging for a picture-like view of fish-holding structure beneath and around your boat.
Simrad SonicHub&erg;2 & Bluetooth® Audio Integration
If you're not at home on the water without a good soundtrack, the Simrad SonicHub®2 marine audio system is the perfect companion to a GO9 XSE display. Stream music from Bluetooth® connected tablets, smartphones, and other mobile devices, play MP3 files from a USB flash drive, or listen to the SonicHub 2's built-in AM/FM radio. SonicHub 2 brings complete control of your audio entertainment to your GO9 XSE display, eliminating the need for a separate stereo head-unit and letting you listen to your music, your way.
GoFree cloud enabled with Built-in Wi-Fi
With Wi-Fi built in, the Simrad GO9 XSE provides direct access to GoFree cloud services including easy wireless map downloads, software updates, and more. Whether hooked up to your home Wi-Fi with your boat trailered in the driveway, logged in to your marina's Wi-Fi, or tethered to your smartphone out on the lake, you can access GoFree cloud services anywhere you have an internet connection. On the water, GoFree connects the Simrad GO9 XSE to your mobile devices, mirroring your display's screen on your smartphone or giving you full remote control from your tablet with the free GoFree Controller app.
SiriusXM Weather Integration
The Simrad GO9 XSE is the only GO Series display compatible with SiriusXM Marine satellite weather, via the optional WM-3 expansion module, for real-time access to weather information right on your display. With onboard access to weather radar, surface buoy reports, NOAA Marine Zone forecasts and more, you can check out the conditions offshore before you even leave the dock. SiriusXM Marine is a subscription service, exclusively available within North America.
* Built-in GPS receiver works in any bracket-mount installation, and when flush-mounted with most fibreglass hulls. When flush-mounted in a metal hulled vessel, an external GPS receiver such as the Simrad GS25 may be required.
Specifications:
- Casing: PC/ABS
- Operating temp: -15°C to +55°C (+5°F to +131°F)
- Water ingress: IPX6 and 7
- Weight (excluding mounting hardware): 1.315 kg (2.9 lbs) - GO9 XSE
- Screen brightness: 1200 nits
- Screen resolution: 480 x 800 (H x W)
- Viewing angle in degrees (typical value at contrast ratio = 10): L/R: 70, top: 50, bottom: 60
- Operating voltage: 10 - 17 V DC
- Current draw at 13.6 V (sonar off, max B/L): 1 A
- Low power standby mode: yes
- Protection: reverse polarity and temporary over-voltage to 36 V
- Alarm output current: 1 A max
- Processor: iMX61 single core
- Conformity: CE, C-Tick
- NMEA 2000 (compliant):1 port (Micro-C male) -,network load 1 LEN : 1 combined port Power and NMEA 2000 (7 pin connector)
- Sonar 1 port (9 pin connector) Radar 1 port (5 pin Ethernet connector)
- Card reader: Dual microSD
Comes With:
- 000-10421-001 - 4G Radar Simrad, 20m cable, RI10 Interface box, 6ft Yellow ethernet Cable
- 000-12568-001 - TotalScan Skimmer Mid/High 455/800
- 000-13702-001 - Gimbal bracket, GO9,V9
- 000-13700-001 - GO9 / V9 Bezel Replacement
- 000-13699-001 - GO9/V9 Dash mount kit
- 000-00128-001 - Power Cable
- 000-13698-001 - GO9 XSE Suncover
Specifications:
- Array Size (Inches): 19.2'
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics/C-Map
- Cartography Type: Platinum/Gold/Hotmaps
- Hor/Vert Beam Width: 5.2deg/25deg
- Included Transducer: 000-12568-001
- Internal/External Antenna: Internal
- Range - Max (Miles): up to 36nm
- Resolution (VxH): 480 x 800
- Screen Size: 9'
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Transom Mount
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 26"H x 25"W x 25"L WT: 45.5 lbs
- UPC: 9420024161593
Simrad OP12 Autopilot Controller
$269.00
OP12 Autopilot Controller
The OP12 wired remote seamlessly integrates with Simrad autopilot systems to provide intuitive mode control, course adjustments, and power steering. Designed to complement the low-profile design of Simrad glass bridge instruments and displays, this remote can be combined with the IS42 Colour Instrument Display to create a standalone autopilot controller, or used as a dedicated autopilot keypad for GO, NSS and NSO evo2 multifunction displays.
Features:
- Intuitive operation
- Easy installation
- Combine with an IS42 display for full autopilot control
- Compatible with Simrad AC12, AC42, NAC-2 and NAC-3 autopilot computers
- Use alongside NSS & NSO evo2 MFD's as an additional Autopilot Controller
- Low-profile glass helm design
- Low power consumption
- Certified NMEA 2000® connectivity
Specifications:
- Dimensions: 60 x 115 x 32mm (2.4" x 4.5" x 1.3")
- Weight: 0.12kg (0.3lbs)
- Power Consumption: 1.4 Watts
- Network Load: 3 LEN
- Color: Black
- Environmental Protection, Waterproof: Waterproof rating: IPx7
- Environmental Protection, Humidity: Up to 95% RH
- Compass Safe Distance: 300mm (1.0")
- Temperature Operating: -15 to +55°C (5°F to +131°F)
- Temperature Storage: -30 to +70 °C (-22 to +158 °F)
Specifications:
- Box Dimensions: 5"H x 6"W x 9"L WT: 0.8 lbs
- UPC: 9420024155127
Simrad NSO evo2 Single 19" Multi-Touch Monitor Bundle
$6,999.00
NSO evo2 Dual 19" Multi-Touch Monitor Bundle with OP50 & GS25 GPS Antenna
Features
- Large-Screen Navigation System
- Multi-TouchSensible (with compatible display)
- Dual Independent Video Output
- Full HD Video
- Performance Module compatibility
- Cartography Choice
- Smaller, lighter design
- Quad-Core Processing Power
- Multi zoom touch gestures
- Naviconics Depth Highlight range
- Naviconics shallow water highlight
- AIS Sarts
- Fusion Link Audio Device Support
- Grib Weather
- FLIR Camera integration
- GS25 Antenna Configuration
- Wide screen display support
- Independent HDMI output ports allow different setups on each display
- 2 x Quad core processors
GoFree
- Control both NSO evo2 monitors direct from your Ipad or Android Tablet.
- NSO evo2 Appears as 2 Separate MFD Displays within the GoFree Application.
Chartography Options
Choose from the many available Cartography options on offer to best suit your Location and usage -C-MAP MAX-N -Navionics -Insight -Insight Genesis -NV Digital Chart
Control Options
OP-50 Remote -Full NSO evo2 System control available with OP-50 Remote -*Integrated NSO evo2 Autopilot control functions require OP-50 remote
Touch screen Control - NSO evo2 can be operated by multi-touch monitors provided by select partners. Currently KEP marine Glass bridge touch screen monitors are certified for use on NSO evo2 and operate via USB cable connection. Multi touch gestures are supported for chart zoom / sonar zoom/ Radar range
MO-T Monitors
Features:
- Low Profile Glass Bridge Design
- More Screen, Less Border
- Widescreen Displays, HD Resolutions
- Touch/Non-Touch Option
- High Bright Backlight Option
- Picture in Picture
- On-Glass Menu Keys
- VESA bracket Mounting Option
- IP66 in Dash Mounting
- Suitable for any monitor application (not limited to Simrad)
High Definition Widescreen Displays
- Higher Definition LCD panels enable more information to be presented on the display
- For a defined chart zoom level, user can see a larger area of chart in full detail
- For an echo sounder panel, more vertical pixels means more vertical resolution and target detail in the water column
- Wide LCD format makes more effective use of boat dashboard space
- Widescreen aspect ratios give more usable panel shapes in split modes
000-10998-001 NSO EVO2 Insight Processor Unit
000-11262-001 MO19-T Monitor
000-12364-001 OP50 Remote
000-11043-001 GS25 GPS Antenna
000-11245-001 Card Reader
000-11248-001 HDMI Cable 3M
000-11247-001 Touch Monitor Serial Cable 2M
Specifications:
- Box Dimensions: 13"H x 25"W x 24"L WT: 30 lbs
- UPC: 9420024157848
Simrad S5100 Module Redefining High-Performance Sonar
$1,999.00 $2,100.00
S5100 Module Redefining High-Performance Sonar
The S5100 high-performance CHIRP sonar module delivers true simultaneous coverage of up to three different depth ranges, at high resolution, making it the perfect sonar solution for offshore sportfishing anglers.
Simultaneous split-screen viewing capability puts you in complete control of the water column; while advanced processing technology allows you to fish with noise-free clarity at all depth ranges without ever losing bottom depth tracking.
Mix and match your favorite transducer coverage and transmit power for wide and narrow beam-widths to reveal more fish, detecting small and tightly spaced fish and identifying thermoclines - or adjust specific CHIRP frequencies from 28 to 250 kHz to precisely target specific depths producing big, crisp arches with clear target separation.
Features:
- 3 fully independent sonar channels deliver high-resolution coverage
- Noise-free clarity at all depth ranges
- Combine any three frequency ranges to target multiple depths, including Ultra-Low, Low, Medium, or High CHIRP
- Compatible with wide-angle CHRIP transducers for greater coverage of the water column
- Simultaneous split-screen viewing of multiple depth ranges on your display
- Maximum depth of 3,000 meters/10,000 feet (transducer dependent)
- Easy to install with three plug-and-play 9-pin transducer connectors
- Compatible with Simrad NSS evo3 and NSS evo2 multifunction displays, NSO evo2 systems and S2000-series fishfinders
Specifications:
- Box Dimensions: 7"H x 16"W x 17"L WT: 13.8 lbs
- UPC: 9420024154595
Simrad RF300 Rudder Feedback
$267.99 $290.00
Rudder Feedback
Simrad rudder feedback units are high resolution units which contribute to gentle yet accurate steering that characterize the Simrad autopilots. They are rugged units designed to withstand the environment. Though Simrad now offers the virtual rudder feedback VRF for outboards and stern drive boats up to 40', it is neccessary to display rudder angle on your autopilot.
Specifications:
- Box Dimensions: 3"H x 4"W x 15"L WT: 1.7 lbs
- UPC: 809190313484
Simrad RPU80 All Regions Reversible Pump - 12V
$847.00
RPU80 All Regions Reversible Pump - 12V
For Cylinder Displacement of 4.9 - 15.2 cu. in. (AC12 required). 12V DC
The RPU80 is a reversible hydraulic steering pump for boats up to 35'
Key Features
- Reversible Pump
- Moderate Flow Rate
- 12V DC
- 80-250 cc
Specifications:
- Box Dimensions: 5"H x 5"W x 12"L WT: 7.4 lbs
- UPC: 809190358638
Simrad RS12 DSC VHF Radio
$199.00 $239.00
RS12 DSC VHF Radio
Communicate clearly with this dependable and versatile Class D DSC Approved marine VHF Radio. Fully loaded with features and ideal for a variety of boats from small RIBs to larger cruisers.
Features
- Single station, JIS-7 waterproof, fully compliant Digital Select Calling (DSC), custom 4-line display, and GPS capable
- Highly visible backlit LCD Display
- NMEA2000 compatible
- 10 weather channels (U.S. Only)
- Easy grip, molded microphone, quick keys provides simple and reliable operation, while the built-in speaker delivers crisp, sharp audio.
- Supports all Internatinal Marine Channels
- Easy access to digital Select Calling (DSC) functions
- Class D and SC-101 compliant for global use with selectable Dual and Tri Watch modes
- Three user-programmable channels
- Equipped with memory retention, and can log up to 10 distress calls and 20 individual DSC calls
- Quick keys for 16/9, 3CH/+/- provide quick channel changing, plus CALL, EXIT, SCAN, and MENU buttons for simple operation
- ATIS function, 20 user-programmable names with MMSI and a second receiver for Channel 70
*The RS12 comes complete with yoke, rear flush mounting kit, power and NMEA interface cables.
Specifications:
- Channels - Available: All US, Canadian, International
- DSC Class: RTCM SC101
- Hailer/Intercom: N/A
- Remote Mic Capable: No
- Scrambler Capable: No
- Waterproof Rating: Waterproof
- Box Dimensions: 4"H x 9"W x 13"L WT: 4.5 lbs
- UPC: 9420024118726
Owner's Manual (pdf)
Simrad NSS12 evo3 Chartplotter/Fishfinder with Insight Chart
$3,499.00
NSS12 evo3 12" Chartplotter/Fishfinder MFD
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder
technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS12 evo3 features a 12-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 12-inch widescreen SolarMAX HD display.
- Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
- Add StructureScan® 3D imaging, advanced Broadband Sounder capabilities and more via Simrad modules
- Expand your view with Halo Pulse Compression radar, Broadband 3G/4G, and other Simrad radar solutions
- Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
- NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
- Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
- Built-in GoFree Wi-Fi enables online features and smartphone monitoring/tablet control
- Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
- Includes Insight chart
- Dimensions without bracket and knobs: 13.84"w x 8.87H
- Dimensions with brack and knbos: 14.85"w x 9.47"h
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics/C-Map
- Cartography Type: Navionics+/Platinum+/Max - N+
- Frequency: 40-250kHz 455-800kHz
- Internal/External Antenna: Internal
- Resolution (VxH): 800 x 1280
- Screen Size: 12'
- Screen Type: cOLOR
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Waypoints/Routes: 6000/500
- Weather Capable: Yes
- Box Dimensions: 9"H x 14"W x 18"L WT: 14.4 lbs
- UPC: 9420024154052
Simrad Verado Hydraulic Kit
$204.99 $219.00
Verado Hydraulic Kit
Kit Includes:
- (1) Return hose 1, 9M(6') 3/8"ID with SAE 5/8"IR coupling
- (2) Tee-4-ORFS: ORFS 04 x ORFS 04 x SAE 7/16"-20 UNF
- (1)Tee-fitting with 3/8" barbs for return hose connection
- (1) SAE 5/8"-18-7/16"-20 UNF Flare for pump unit return
- (3) Non-Corrosive hose clamps, 5/16-9/16"
Specifications:
- Box Dimensions: 3"H x 9"W x 12"L WT: 2 lbs
- UPC: 809190313910
Simrad Power Cable - 2m - NSE & StructureScan 3D
$41.99 $49.99
Simrad Power Cable f/NSE & StructureScan 3D
4 pin conn. to 4 bare wires for power in - power control bus and external alarm - 6.5 ft (2 m).
Simrad 3G Broadband Radar Dome f/NSE, NSO & NSS Series w/20M Cable
$1,499.00 $1,699.00
Broadband 3G Radar with 20M Cable
Faster, better, longer...
Join the Broadband Radar revolution for superior short-range target detection and unrivalled target separation.
- Crystal Clear Images
- Zero Radiation Hazard
- InstantOn
- Low Power Consumption
- Mount Anywhere
- Quick Installation
- Unrivalled Short-Range Performance
- 10 MARPA Targets
Now with 30% more range.
Broadband 3G Radar allows you to see more targets farther away from your boat. Now you get the same impressive short-range capabilities of the original Broadband Radar with the addition of exposing targets previously unseen before.
Unparalleled Short Range Target Discrimination - Where it Matters Most
Simrad Yachting's Broadband Radar provides amazing target resolution, even at an unprecedented 1/32 nm range. Docks, channel markers, moored vessels and other critical targets are displayed with clarity and separation, for added confi dence in close quarters. Broadband Radar technology also eliminates the "main bang" of a pulse radar - the obscured "dead zone" immediately around the vessel - which interferes with close target detection.
Lowest RF Transmission for Safe, Flexible Installation
Because Simrad Broadband Radar transmits at 1/10,000 the power of typical pulse radars (emitting 5 times less energy than an average cell phone), the radome is safe to mount in locations never before possible. In addition, the lowest DC power draw of any X-band marine radar makes this system ideally suited for sailboats and other vessels with limited power.
Navigation in an Instant
No more waiting 2-3 minutes for a magnetron to warm up - 100% solid-state design provides InstantOn capability. When darkness falls or the fog rolls in, you will always be ready. Ideal for sailboats wishing to save power, or boats at anchor not wishing to run the radar continuously.
SPECIFICATIONS
RADAR
Antenna Beam Width Horizontal 5.2°+/-10% (-3dB width) °
Antenna Beam Width Vertical 25°+/-20% (-3dB width) °
Antenna Receiver Noise Figure 6 dB
Antenna Rotation Speed 24/36 rpm +/- 10% RPMs
Radar Warm Up Time 0 min
Radar Wind Resistance 51 m/sec (Max:100 Knots)
COMMUNICATIONS
Transmitter Frequency X-band - 9.3 to 9.4Ghz
Transmitter Power Output 165mW nominal
Data I/O Protocol High Speed Ethernet
TECHNICAL / ENVIRONMENTAL
Mounting Bolts: 4x30xM8 - 304 stainless steel
Waterproof Standard IPX6
Height 280 mm \ 11 in
Diameter 488 mm \ 19.2 in
Weight 7.4 kg \ 16.31 lbs
Humidity +35°C (95xF) 95% RH
POWER
Power Supply 9V to 31.2Vdc (12/24 Volt systems) Reverse polarity protection vDC
Power Consumption 18W (Typ.) @ 13.8Vdc
Power Consumption Standby 2W (Typ.) @ 13.8Vdc - only 150ma
GENERAL
Compliance CE, FCC (ID: RAY3G4G), IC: 4697A-3G4G
OTHER
Interconnection Cable 20M (66ft) standard with RJ45 thin custom (Max 30m)
Interface Heading SimNet or NMEA 0183 with cable kit into display
Operating Temperature -25° to +55°C (-13° to +130°F)
Specifications:
- Array Size (Inches): 11 x 19.2
- Box Dimensions: 14"H x 22"W x 24"L WT: 32.15 lbs
- UPC: 9420024111000
Owner's Manual (pdf)
Brochure (pdf)
Simrad GO5 XSE Combo with Med/Hi DownScan Transom Mount Transducer & Navionics+ Chart
$539.00
B>Simrad GO5 XSE Combo - Med/Hi/DownScan 455/800 HDI Transom Mount Transducer & Navionics+ Chart
Get more from every day on the water with the Simrad GO5 XSE, a perfect fit for compact sportboats and dayboats. Behind its super-bright touchscreen lies a chartplotter with built-in GPS receiver, and Wi-Fi access to the latest charts and updates. Control your onboard sound system, monitor engine data and more over NMEA 2000®, and choose from an array of built-in sonar technologies: cruise with confidence using ForwardScan forward-looking sonar, or find fish like a pro with Broadband Sounder CHIRP sonar plus StructureScan® HD SideScan and DownScan Imaging.
Key Features
- Easy to use multi-touch interface
- Navionics+ Chart with all USA, Canada and Hotmaps Premium
- Full-featured chartplotter with widest available cartography support (Insight, Navionics, CMAP)
- Plan smarter with TripIntel technology
- 5-inch flush or bracket mount display
- Widescreen with bright LED backlight
- High-speed 10 Hz GPS receiver
- Broadband echosounder with CHIRP
- Built-in ForwardScan sonar (transducer required)
- Built-in StructureScan® imaging (transducer required)
- Built-in GoFree Wi-Fi
- NMEA 2000® compatible
Specifications:
- Weight:537g (1.18lb)
- Power Consumption:900mA @ 13.5V
- Network Load (LEN):1
- Color:Black
- Display Size:5" Diagonal
- Type:TFT, Super Wide View
- Resolution:800x480
- Illumination:1200nits
- Environmental Protection:IPX7
- Operating Temperature:-15°C to +55°C
Overview
Easy to Use Multi-Touch Display
The GO5 XSE offers true ease of use with intuitive touchscreen controls that smartphone and tablet users will find instantly familiar. Tap to create or select waypoints, pinch to zoom, or tap and drag to pan smoothly across charts. Simple home screen and menu layouts make all functions quickly accessible, with large and clearly-captioned icons that are easy to recognise and tap.
Chartplotter Navigation & Waypoint Management
The GO5 XSE is a full-featured chartplotter, with support for the widest available range of cartography options including C-MAP® MAX-N, Navionics®, Insight®, Insight Genesis®, and NV Digital® Charts. Navigate confidently to destinations near and far, with the flexibility to choose charts that best fit your needs and location. Set and record those destinations easily with simple waypoint mangement: mark waypoints with a touch, and assign meaningful names that make it easy to look up your desired destination whether you've mapped out ten places or a thousand.
Fully Customisable Interface
The Simrad GO5 XSE is fully customisable to suit your vessel and your favourite on-water activities - from power boating, to fishing, to water sports. Customise your home screen with shortcuts to the features you use most, and personalise it with your choice of wallpaper. Adjustable split-screen views and customisable panel layouts let you see everything you need on-screen at once, whatever your activity.
Plan Smarter with TripIntel Technology
Designed for power boaters, TripIntel technology tracks and displays the key information you need to plan safe and enjoyable days on the water. Make smart decisions with fuel range overlaid on charts, easy access to current and future tide levels, and a detailed history of your previous trips including the route you took and how your boat performed.
Built-in 10 Hz GPS receiver*
With a high-speed GPS receiver updating your position ten times every second, the Simrad GO5 XSE is ideal for use aboard fast-moving RIBs and powerboats. Watch your boat's movement tracked smoothly, accurately, and in real-time, without 'jumping' from point to point on the display.
Cruise Charting View
Designed with power boating in mind, the Simrad GO5 XSE offers a unique Cruise Charting page that brings together crucial navigation data and charts in one easily readable display. Choose the information most relevant to your crusing style and on-water activities with the ability to edit on-screen data items.
NMEA 2000® Engine Monitoring & Instrumentation
The Simrad GO5 XSE connects to any NMEA 2000®-capable equipment aboard your vessel including outboard and inboard engines; fuel level and flow meters; speed, heading, and water temperature sensors; and much more. Create your own custom digital instrument displays, bringing a wealth of information to even the most crowded dash while keeping a clean look with as few gauges as possible.
Watch Your Depth with Built-in Sonar
Knowing the true depth beneath your hull can help you enjoy your time on the water with fewer worries, and makes it easier to locate suitable anchorages in unfamiliar waters. With built-in sonar, just add a suitable sonar transducer for accurate, real-time depth tracking. A scrollable depth history view lets you track back and easily set waypoints for promising anchorages, while StructureScan Imaging combines DownScan and SideScan sonar to offer a picture-like view of the bottom beneath your vessel (With Optional Transducer)
Cruise Confidently with ForwardScan Sonar
Using an optional ForwardScan transducer, this forward-looking sonar technology provides a clear two-dimensional image of the bottom in front of your vessel, allowing you to navigate shallow or poorly-charted waters with confidence. With real-time updates and a forward-looking view of up to eight times your current depth, ForwardScan lets you relax and enjoy a safer day on the water.
Find fish with CHIRP & StructureScan® HD sidescan imaging
Whether fishing is your life or just a casual hobby, any fishing trip will benefit from the extensive array of built-in sonar technology on the Simrad GO5 XSE. Add a suitable transducer, available separately or bundled with your display, and the GO5 XSE works as a powerful fishfinder with CHIRP-enabled broadband sonar for clear detection of fish throughout the water column. With an optional HDI or TotalScan transducer, the GO5 XSE also offers StructureScan HD sidescan imaging for a picture-like view of fish-holding structure beneath and around your boat.
Simrad SonicHub®2 & Bluetooth® Audio Integration
If you're not at home on the water without a good soundtrack, the Simrad SonicHub®2 marine audio system is the perfect companion to a GO5 XSE display. Stream music from Bluetooth® connected tablets, smartphones, and other mobile devices, play MP3 files from a USB flash drive, or listen to the SonicHub 2's built-in AM/FM radio. SonicHub 2 brings complete control of your audio entertainment to your GO5 XSE display, eliminating the need for a separate stereo head-unit and letting you listen to your music, your way.
GoFree cloud enabled with Built-in Wi-Fi
With Wi-Fi built in, the Simrad GO5 XSE provides direct access to GoFree cloud services including easy wireless map downloads, software updates, and more. Whether hooked up to your home Wi-Fi with your boat trailered in the driveway, logged in to your marina's Wi-Fi, or tethered to your smartphone out on the lake, you can access GoFree cloud services anywhere you have an internet connection. On the water, GoFree connects the Simrad GO5 XSE to your mobile devices, mirroring your display's screen on your smartphone or giving you full remote control from your tablet with the free GoFree Controller app.
* Built-in GPS receiver works in any bracket-mount installation, and when flush-mounted with most fibreglass hulls. When flush-mounted in a metal hulled vessel, an external GPS receiver such as the Simrad GS25 may be required.
Specifications:
- Basemap: Yes
- Card Format: Micro SD
- Cartography - Preloaded: No
- Cartography Brand: Navionics/C-Map
- Cartography Type: Gold/HotMaps Premium
- Frequency: 83/200/455/800
- Included Transducer: 000-12570-001
- Internal/External Antenna: Internal
- Resolution (VxH): 800x480
- Screen Size: 5'
- Screen Type: Color
- Speed/Temp: Temp Only
- Touchscreen: Yes
- Transducer Type: Transom Mount
- Waterproof Rating: Waterproof
- Weather Capable: No
- Box Dimensions: 8"H x 9"W x 11"L WT: 5 lbs
- UPC: 9420024154731
Simrad GO9 XSE Chartplotter/Fishfinder - No Transducer
$1,049.00
GO9 XSE Chartplotter/Fishfinder - No Transducer
GO9 XSE Multi-function display with built in Echosounder, GPS and Wi-Fi. Super-bright, 9" multi-touch widescreen display with NMEA 2000 and radar interface.
Features:
- Easy to use, High brightness 9" tablet style touchscreen
- Built-in advanced echosounder capable of displaying CHIRP, Forwardscan, Sidescan and Downscan images
- Radar port for connection to a Simrad solid state radar
- Direct Audio, Autopilot, communication and engine connection and control over NMEA2000
- Built-in WiFi for mobile device mirroring and internet downloads of charting and software
- Easy to use multi touch software
- Safely and easily navigate using your favourite cartography (Insight, Navionics, CMAP)
- Determine depth, bottom type and find fish using one of the many echosounder technology options
- Quick and simple control of entertainment systems connected on NMEA2000
- Vessel circuit control when connected to a C-zone digital switching system
- View and monitor engine data while underway
- Low Profile Glass dash styling
- Super bright widescreen display
- Built in Wi-Fi connectivity
- Software update notifications and downloads when connected to the internet
- Screen mirroring when connected to a mobile device
- Built in 10 Hz GPS antenna
- Dual Micro SD card slot
- Built in echosounder (Broadband & Chirp)
- Built in DownScan and Sidescan Imaging (transducer required)
- Built in Forwardscan Imaging (transducer required)
- Radar port for direct connection to Simrad 3G/4G or Halo Radar scanners
- Operable with OP40/OP50 Remote
- Advanced NMEA2000 networking
Easy to Use Multi-Touch Display
The GO9 XSE offers true ease of use with intuitive touchscreen controls that smartphone and tablet users will find instantly familiar. Tap to create or select waypoints, pinch to zoom, or tap and drag to pan smoothly across charts. Simple home screen and menu layouts make all functions quickly accessible, with large and clearly-captioned icons that are easy to recognise and tap.
Chartplotter Navigation & Waypoint Management
The GO9 XSE is a full-featured chartplotter, with support for the widest available range of cartography options including C-MAP® MAX-N, Navionics®, Insight®, Insight Genesis®, and NV Digital® Charts. Navigate confidently to destinations near and far, with the flexibility to choose charts that best fit your needs and location. Set and record those destinations easily with simple waypoint mangement: mark waypoints with a touch, and assign meaningful names that make it easy to look up your desired destination whether youve mapped out ten places or a thousand.
Expand Your View with a Simrad Radar Solution
The Simrad GO9 XSE is a full-featured radar display with plug-and-play connectivity to Simrad Broadband 3G, Broadband 4G, and Halo Pulse Compression radar systems. Cruise confidently through crowded harbours, navigate safely in poor visibility, keep an eye on distant weather cells, and find flocks of feeding birds that hint at good fishing spots. Automatic tuning helps to provide a clear radar picture in any conditions, while radar overlay combines radar data with navigational charts for an easy-to-interpret view of your surroundings.
Fully Customisable Interface
The Simrad GO9 XSE is fully customisable to suit your vessel and your favourite on-water activities from power boating, to fishing, to water sports. Customise your home screen with shortcuts to the features you use most, and personalise it with your choice of wallpaper. Adjustable split-screen views and customisable panel layouts let you see everything you need on-screen at once, whatever your activity.
Plan Smarter with TripIntel Technology
Designed for power boaters, TripIntel technology tracks and displays the key information you need to plan safe and enjoyable days on the water. Make smart decisions with fuel range overlaid on charts, easy access to current and future tide levels, and a detailed history of your previous trips including the route you took and how your boat performed.
Built-in 10 Hz GPS receiver*
With a high-speed GPS receiver updating your position ten times every second, the Simrad GO9 XSE is ideal for use aboard fast-moving RIBs and powerboats. Watch your boat's movement tracked smoothly, accurately, and in real-time, without 'jumping' from point to point on the display.
Cruise Charting View
Designed with power boating in mind, the Simrad GO9 XSE offers a unique Cruise Charting page that brings together crucial navigation data and charts in one easily readable display. Choose the information most relevant to your crusing style and on-water activities with the ability to edit on-screen data items.
NMEA 2000® Engine Monitoring & Instrumentation
The Simrad GO9 XSE connects to any NMEA 2000®-capable equipment aboard your vessel including outboard and inboard engines; fuel level and flow meters; speed, heading, and water temperature sensors; and much more. Create your own custom digital instrument displays, bringing a wealth of information to even the most crowded dash while keeping a clean look with as few gauges as possible.
Watch Your Depth with Built-in Sonar
Knowing the true depth beneath your hull can help you enjoy your time on the water with fewer worries, and makes it easier to locate suitable anchorages in unfamiliar waters. With built-in sonar, just add a suitable sonar transducer for accurate, real-time depth tracking. A scrollable depth history view lets you track back and easily set waypoints for promising anchorages, while StructureScan Imaging combines DownScan and SideScan sonar to offer a picture-like view of the bottom beneath your vessel.
Cruise Confidently with ForwardScan Sonar
Using an optional ForwardScan transducer, this forward-looking sonar technology provides a clear two-dimensional image of the bottom in front of your vessel, allowing you to navigate shallow or poorly-charted waters with confidence. With real-time updates and a forward-looking view of up to eight times your current depth, ForwardScan lets you relax and enjoy a safer day on the water.
Find fish with CHIRP & StructureScan® HD sidescan imaging
Whether fishing is your life or just a casual hobby, any fishing trip will benefit from the extensive array of built-in sonar technology on the Simrad GO9 XSE. Add a suitable transducer, available separately or bundled with your display, and the GO9 XSE works as a powerful fishfinder with CHIRP-enabled broadband sonar for clear detection of fish throughout the water column. With an optional HDI or TotalScan transducer, the GO9 XSE also offers StructureScan HD sidescan imaging for a picture-like view of fish-holding structure beneath and around your boat.
Simrad SonicHub®2 & Bluetooth® Audio Integration
If you're not at home on the water without a good soundtrack, the Simrad SonicHub®2 marine audio system is the perfect companion to a GO9 XSE display. Stream music from Bluetooth® connected tablets, smartphones, and other mobile devices, play MP3 files from a USB flash drive, or listen to the SonicHub 2's built-in AM/FM radio. SonicHub 2 brings complete control of your audio entertainment to your GO9 XSE display, eliminating the need for a separate stereo head-unit and letting you listen to your music, your way.
GoFree cloud enabled with Built-in Wi-Fi
With Wi-Fi built in, the Simrad GO9 XSE provides direct access to GoFree cloud services including easy wireless map downloads, software updates, and more. Whether hooked up to your home Wi-Fi with your boat trailered in the driveway, logged in to your marina's Wi-Fi, or tethered to your smartphone out on the lake, you can access GoFree cloud services anywhere you have an internet connection. On the water, GoFree connects the Simrad GO9 XSE to your mobile devices, mirroring your display's screen on your smartphone or giving you full remote control from your tablet with the free GoFree Controller app.
SiriusXM Weather Integration
The Simrad GO9 XSE is the only GO Series display compatible with SiriusXM Marine satellite weather, via the optional WM-3 expansion module, for real-time access to weather information right on your display. With onboard access to weather radar, surface buoy reports, NOAA Marine Zone forecasts and more, you can check out the conditions offshore before you even leave the dock. SiriusXM Marine is a subscription service, exclusively available within North America.
* Built-in GPS receiver works in any bracket-mount installation, and when flush-mounted with most fibreglass hulls. When flush-mounted in a metal hulled vessel, an external GPS receiver such as the Simrad GS25 may be required.
Specifications:
- Casing: PC/ABS
- Operating temp: -15°C to +55°C (+5°F to +131°F)
- Water ingress: IPX6 and 7
- Weight (excluding mounting hardware): 1.315 kg (2.9 lbs) - GO9 XSE
- Screen brightness: 1200 nits
- Screen resolution: 480 x 800 (H x W)
- Viewing angle in degrees (typical value at contrast ratio = 10): L/R: 70, top: 50, bottom: 60
- Operating voltage: 10 - 17 V DC
- Current draw at 13.6 V (sonar off, max B/L): 1 A
- Low power standby mode: yes
- Protection: reverse polarity and temporary over-voltage to 36 V
- Alarm output current: 1 A max
- Processor: iMX61 single core
- Conformity: CE, C-Tick
- NMEA 2000 (compliant):1 port (Micro-C male) -,network load 1 LEN : 1 combined port Power and NMEA 2000 (7 pin connector)
- Sonar 1 port (9 pin connector) Radar 1 port (5 pin Ethernet connector)
- Card reader: Dual microSD
Comes With:
- 000-13702-001 - Gimbal bracket, GO9,V9
- 000-13700-001 - GO9 / V9 Bezel Replacement
- 000-13699-001 - GO9/V9 Dash mount kit
- 000-00128-001 - Power Cable
- 000-13698-001 - GO9 XSE Suncover
Specifications:
- Screen Type: Color
- Screen Size: 9'
- Resolution (VxH): 480 x 800
- Internal/External Antenna: Internal
- Cartography Type: Gold/Platinum
- Cartography Brand: Navionics/C-Map
- Cartography - Preloaded: No
- Card Format: Micro SD
- Basemap: Yes
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 9"H x 10"W x 13"L WT: 6 lbs
- UPC: 9420024153673
Simrad RPU160 Drive Unit Reversible Pump - 12V DC, 9.8-22.5 Cu. In.
$1,022.00
RPU160 Drive Unit Reversible Pump - 12V DC, 9.8-22.5 CU In
The RPU160 is a reversible hydraulic steering pump for boats up to 50'. It works in conjunction with the AC42 autopilot computer as part of an autopilot system.
Features:
- Reversible Pump
- Moderate Flow Rate
- 12V DC
- 160-550 cc
Specifications:
- Box Dimensions: 5"H x 5"W x 12"L WT: 7.8 lbs
- UPC: 809190358683
Simrad NSS7 evo2 Combo Multifunction Display Insight
$999.00
NSS7 evo2 Combo Multifunction Display
The NSS evo2 combines form, fit and function in an easy-to-use multifunction device. The integrated NSS evo2 MFD features a sleek display with TouchSensible™ multi-touch interaction. TouchSensible, provides precision interaction in any sea condition with its logical keypad input and rotary, push-to-enter knob. With its widescreen 16:9 display, integrated StructureScan™ and Broadband sonar, and expandability the NSS evo2 is well suited for center consoles, sportfishing and power cruising boats.
Key Features
- Low Profile Glass Design
- More Screen, Less Border
- Widescreen, Multi Touch Display
- Built in High Gain 10Hz GPS/GLONASS
- Built in CHIRP/Traditional sonar
- Built in StructureScan
- 4 display sizes 7”, 9”, 12” & 16”
- High Brightness Displays
- All new HEROiC Software
- OP40 remote operable
- Chartplotter only versions available
- Networks with existing NSS, NSE, NSO series MFDs
- Networks with all Simrad Performance Modules
- 8mm Dash Profile: Family Matched with New MO Monitors
- OP40 Remote Controllable
- All new HEROiC Software has been engineered for ease of use and to maximise the benefits of widescreen multi-touch display technology.
- HEROiC has an all new look and feel for Simrad while maintaining the familiar features for the seasoned Simrad user
- HEROiC has been designed for mixed-mode user control to provide a powerful multi touch user interface that can also be operated by a keypad when the sea conditions get challenging
- HEROiC software is more customisable, allowing users to completely configure the system to their needs.
- Personalised Wallpaper
- Fully customisable favourites that can be accessed by a long press of the ‘Home’ key: HEROiC utilizes multitouch gestures for object manipulation and menu access. These types of controls are mainstream in todays Tablet/Smartphone market and very intuitive and easy to adapt to.
- Pinch to zoom Chart, Echo, Radar
- Drag the status bar down from the top of the display to access system controls
- OP40 Remote Controllable
NSS evo2 inherits all the existing software feature from NSS RTM 3.0 plus more new for evo2:
- FLIR M-Series camera control
- OP40 Remote controllable
- Dual Radar
- 48RPM Radar Support
- BEP C-Zone Integration
Specifications:
- Basemap: Yes
- Card Format: MicroSD/SD
- Cartography - Preloaded: Yes
- Cartography Brand: Navionics
- Cartography Type: Platinum/Gold/Hotmaps
- Internal/External Antenna: Internal
- Resolution (VxH): 800 x 480
- Screen Size: 7
- Screen Type: Color
- Touchscreen: Yes
- Transducer Type: Not Included
- Waterproof Rating: Waterproof
- Weather Capable: Yes
- Box Dimensions: 9"H x 10"W x 13"L WT: 6.8 lbs
- UPC: 9420024125250
Simrad Broadband 4G Radar w/20m Cable
$1,999.00
Broadband 4G Radar with 20m Cable
Part #: 000-10421-001
Simrad's revolutionary Broadband 4GT Radar offers all of the benefits of the Broadband 3G Radar, including a true 200' working range, plus some spectacular extra features. The Broadband 4G has an impressive 50% improvement in range and target detection capability with a new 36 nautical mile range and 18 range scales to accommodate the increased performance. Broadband 4G is the first dome antenna to employ beamsharpening. This technology enables a new feature called Target Separation Control, which
improves the azimuth resolution - or effective antenna horizontal beamwidth - up to the 2X resolution of any 18" dome. This is equivalent of a 3-1/2 foot open array radar!
When paired with the Simrad NSO and NSE series, the Broadband 4G Radar is capable of high speed operation, up to 48RPM and has a new Dual Range feature, which allows unprecedented simultaneous working ranges, anywhere from 200 feet up to 36 nautical miles. No other radar in the world can do this. The 4G all-around performance results including exceptional clutter rejection are nothing short of mind-blowing, dramatically increasing situational awareness among novice and professional users alike, thus proving the Broadband 4G Radar is the only on-water radar choice.
More Range
50% more true range than Broadband 3G Radar. Now you can see crystal clear targets up to 32nm away and inside strong storm cells more than 17nm away.
Dual Range
Capable of displaying Dual Range radar combination when combined with an NSE or NSO system. Monitor targets from 200 feet to 32nm from a single dome.
High Speed Mode
Select 48 RPM* for almost instant updating at less than 1nm
*48rpm currently available on NSE, NSO and Zeus units only
MARPA Target Tracking
Track up to 10 targets. Track up to 10 targets as standard or up to 20 in Dual Range mode with independent control.
Quick Installation
No reason to open the dome, no tune or zero mile adjustment, and no radar-licensed technician required
Dual Guard Zones
Protect yourself from more angles
True Motion Display
Easily distinguish moving targets from land with
NSS, NSE and NSO.
InstantOn
Solid-state technology produces an immediate,
accurate on-screen image unlike normal warm-up
times associated with magnetron pulse radars.
Low Power Consumption
Ideal for boats of any size, sail, cruise or fish.
Automatic Clarity
Proven auto harbour and offshore modes including
directional clutter rejection.
Extremely Low Emissions
Safer than any other radar currently on the market and emitting less radiation than a mobile phone allowing it to be mounted anywhere.
Broadband 4G Radar kit for Simrad NSO/NSE/NSS series
Includes Scanner, scanner cable 20 m (66 ft), RI10 interface box with
NMEA2000, Yellow ethernet cable - 1.8 m (6 ft)
Specifications:
- Array Size (Inches): 19
- Box Dimensions: 13"H x 22"W x 25"L WT: 32 lbs
- UPC: 9420024111017
Owner's Manual (pdf)
Brochure (pdf)
Simrad N2K Starter Kit
$71.99 $74.95
N2K Starter Kit
NMEA 2000 Network Starter Kit Includes:
- Network power cable
- 4.5M (15') N2K cable
- 3 x T-connectors
- 2 x network terminators
